AXEL LITE Hardware Manual
LVDS1_TX0_P
LVDS1_TX1_N
LVDS1_TX1_P
LVDS1_TX2_N
LVDS1_TX2_P
LVDS1_TX3_N
LVDS1_TX3_P
LVDS1_CLK_N
LVDS1_CLK_P
7.4.2
HDMI
The HDMI interface available on AXEL LITE is based on the HDMI
transmitter and the HDMI 3D Tx PHY integrated into the i.MX6 SoC. The
HDMI port supports the following standards and features:
● High-Definition Multimedia Interface Specification, Version 1.4a
● Support for up to 1080p at 60Hz HDTV display resolutions and up to
QXGA graphic display resolutions.
● Support for 4k x 2k and 3D video formats
● Support for up to 16-bit Deep Color modes
The following table describes the interface signals:
HDMI_CLK_N
Pin name
Conn.
Pin
J2.161
J2.163
J2.165
J2.167
J2.169
J2.171
J2.173
J2.155
J2.157
Pin name
Conn.
Pin
J2.111
Function
signal
LVDS1 positive data 0
signal
LVDS1 negative data 1
signal
LVDS1 positive data 1
signal
LVDS1 negative data 2
signal
LVDS1 positive data 2
signal
LVDS1 negative data 3
signal
LVDS1 positive data 3
signal
LVDS1 negative clock
signal
LVDS1 positive clock
signal
Function
HDMI negative clock
October, 2016
v. 0.9.5
Notes
Notes
43/63
