AXEL LITE Hardware Manual
7.6.3
UART3
The following table describes the interface signals:
UART3_CTS
UART3_RTS
UART3_RX_DATA
UART3_TX_DATA
7.6.4
UART4
The following table describes the interface signals:
UART4_RX_DATA
UART4_TX_DATA
7.6.5
UART5
The following table describes the interface signals:
UART5_CTS
UART5_RTS
UART5_RX_DATA
UART5_TX_DATA
Pin name
Conn.
J2.185
J2.199
J2.201
J2.189
J2.187
Pin name
Conn.
Pin name
Conn.
J2.107
J2.105
Function
Pin
Clear to send
J2.45
Request to send
J2.37
Serial/infrared data
receive
Serial/infrared data
transmit
Function
Pin
J2.91
Serial/infrared data
receive
J2.89
Serial/infrared data
transmit
Function
Pin
Clear to send
Request to send
J2.95
Serial/infrared data
receive
J2.93
Serial/infrared data
transmit
October, 2016
v. 0.9.5
Notes
Notes
Notes
47/63
