Dave Embedded Systems AXEL LITE Hardware Manual page 36

AXEL LITE Hardware Manual
Pin Pin Name
J2.76 CSI0_DAT9
J2.78 CSI0_DAT10
J2.80 CSI0_DAT11
J2.82 DGND
J2.84 CLK1_N
J2.86 CLK1_P
J2.88 CLK2_N
J2.90 CLK2_P
J2.92 PCIE_RXN
J2.94 PCIE_RXP
J2.96 PCIE_TXN
J2.98 PCIE_TXP
J2.100 DGND
J2.102 CSI_CLK0M
J2.104 CSI_CLK0P
J2.106 CSI_D0M
J2.108 CSI_D0P
J2.110 CSI_D1M
J2.112 CSI_D1P
J2.114 CSI_D2M
J2.116 CSI_D2P
J2.118 CSI_D3M
J2.120 CSI_D3P
J2.122 DGND
J2.124 DI0_PIN15
J2.126 DI0_PIN4
J2.128 DI0_PIN3
J2.130 DI0_PIN2
J2.132 DI0_DISP_CLK
J2.134 DISP0_DAT0
J2.136 DISP0_DAT1
J2.138 DISP0_DAT2
J2 – EVEN [2-204]
Internal Connections
CPU.CSI0_DAT9
CPU.CSI0_DAT10
CPU.CSI0_DAT11
DGND
CPU.CLK1_N
CPU.CLK1_P
CPU.CLK2_N
CPU.CLK2_P
CPU.PCIE_RXN
CPU.PCIE_RXP
CPU.PCIE_TXN
CPU.PCIE_TXP
DGND
CPU.CSI_CLK0M
CPU.CSI_CLK0P
CPU.CSI_D0M
CPU.CSI_D0P
CPU.CSI_D1M
CPU.CSI_D1P
CPU.CSI_D2M
CPU.CSI_D2P
CPU.CSI_D3M
CPU.CSI_D3P
DGND
CPU.DI0_PIN15
CPU.DI0_PIN4
CPU.DI0_PIN3
CPU.DI0_PIN2
CPU.DI0_DISP_CLK
CPU.DISP0_DAT0
CPU.DISP0_DAT1
CPU.DISP0_DAT2
October, 2016
Ball/ Supply Type Voltage
pin # Group
N5
M1
M3
-
C7
D7
C5
D5
B1
B2
A3
B3
-
F4
F3
E4
E3
D1
D2
E1
E2
F2
F1
-
N21 NVCC_
P25 NVCC_
N20 NVCC_
N25 NVCC_
N19 NVCC_
P24 NVCC_
NVCC_
P22
NVCC_
P23
v. 0.9.5
Note
36/63
