Dave Embedded Systems AXEL LITE Hardware Manual page 34

AXEL LITE Hardware Manual
Pin Pin Name
J2.173 LVDS1_TX3_P
J2.175 DGND
J2.177 EIM_D19
J2.179 EIM_D20
J2.181 EIM_D21
J2.183 EIM_D22
J2.185 EIM_D23
J2.187 EIM_D24
J2.189 EIM_D25
J2.191 EIM_D26
J2.193 EIM_D27
J2.195 EIM_D28
J2.197 EIM_D29
J2.199 EIM_D30
J2.201 EIM_D31
J2.203 DGND
Pin Pin Name
J2.2 DGND
J2.4 3.3VIN
J2.6 3.3VIN
J2.8 3.3VIN
J2.10 3.3VIN
J2 – ODD [1-203]
Internal Connections
CPU.LVDS1_TX3_P
DGND
CPU.EIM_D19
CPU.EIM_D20
CPU.EIM_D21
CPU.EIM_D22
CPU.EIM_D23
CPU.EIM_D24
CPU.EIM_D25
CPU.EIM_D26
CPU.EIM_D27
CPU.EIM_D28
CPU.EIM_D29
CPU.EIM_D30
CPU.EIM_D31
DGND
J2 – EVEN [2-204]
Internal Connections
DGND
INPUT VOLTAGE
INPUT VOLTAGE
INPUT VOLTAGE
INPUT VOLTAGE
October, 2016
Ball/ Supply Type Voltage
pin # Group
AA4
-
G21
G20
H20
E23
D25
F22
G22
E24
E25
G23
J19
J20
H21
-
Ball/ Supply Type Voltage
pin # Group
-
v. 0.9.5
Note
Note
34/63
