Pinout table

This chapter contains the pinout description of the AXEL LITE module,
grouped in two tables (odd and even pins) that report the pin mapping of
the 204-pin SO-DIMM AXEL LITE connector.
Each row in the pinout tables contains the following information:
Connections
Supply Group
Reference to the connector pin
Pin
Pin Name Pin (signal) name on the AXEL LITE connectors
Internal Connections to the AXEL LITE components:
CPU.<x> : pin connected to CPU (PS, processing system) pad
named <x>
CAN.<x> : pin connected to the CAN transceiver
PMIC.<x> : pin connected to the Power Manager IC
LAN.<x> : pin connected to the LAN PHY
SV.<x>: pin connected to voltage supervisor
MTR: pin connected to voltage monitors
NOR: pin connected to SPI NOR flash
Component ball/pin number connected to signal
Ball/pin #
Power Supply Group
Pin type: I = Input, O = Output, D= Differential, Z = High impedance,
Type
S = Supply voltage, G = Ground, A = Analog signal
Voltage I/O voltage
