AXEL LITE Hardware Manual
Pin Pin Name
J2.53 SD3_DATA7
J2.55 SD3_CMD
J2.57 DGND
J2.59 SD3_CLK
J2.61 SD2_DATA0
J2.63 SD2_DATA1
J2.65 SD2_DATA2
J2.67 SD2_DATA3
J2.69 SD2_CMD
J2.71 SD2_CLK
J2.73 DGND
J2.75 SD1_DAT0
J2.77 SD1_DAT1
J2.79 SD1_DAT2
J2.81 SD1_DAT3
J2.83 SD1_CMD
J2.85 SD1_CLK
J2.87 DGND
J2.89 KEY_COL0/ECSPI1_SCLK
J2.91 KEY_ROW0/ECSPI1_MOSI
J2.93 KEY_COL1/ECSPI1_MISO
J2.95 KEY_ROW1/ECSPI1_SS0
J2.97 KEY_COL2/ECSPI1_SS1
J2.99 KEY_ROW2
J2.101 KEY_COL3/I2C2_SCL
J2.103 KEY_ROW3/I2C2_SDA
J2.105 KEY_COL4
J2.107 KEY_ROW4
J2.109 DGND
J2.111 HDMI_CLKN
J2.113 HDMI_CLKP
J2.115 HDMI_D0N
J2 – ODD [1-203]
Internal Connections
CPU.SD3_DATA7
CPU.SD3_CMD
DGND
CPU.SD3_CLK
CPU.SD2_DATA0
CPU.SD2_DATA1
CPU.SD2_DATA2
CPU.SD2_DATA3
CPU.SD2_CMD
CPU.SD2_CLK
DGND
CPU.SD1_DAT0
CPU.SD1_DAT1
CPU.SD1_DAT2
CPU.SD1_DAT3
CPU.SD1_CMD
CPU.SD1_CLK
DGND
CPU.KEY_COL0
CPU.KEY_ROW0
CPU.KEY_COL1
CPU.KEY_ROW1
CPU.KEY_COL2
CPU.KEY_ROW2
CPU.KEY_COL3
CPU.KEY_ROW3
CPU.KEY_COL4
CPU.KEY_ROW4
DGND
CPU.HDMI_CLKN
CPU.HDMI_CLKP
CPU.HDMI_D0N
October, 2016
Ball/ Supply Type Voltage
pin # Group
F13
B13
-
D14
A22
E20
A23
B22
F19
C21
-
A21 NVCC_
C20 NVCC_
E19 NVCC_
F18 NVCC_
B21 NVCC_
D20 NVCC_
-
W5
V6
U7
U6
W6
W4
U5
T7
T6
V5
-
J5
J6
K5
v. 0.9.5
Note
Not available as ECSPI1 signals on AXEL
LITE's models which mount the NOR SPI
flash. For further details, please refer to
section 3.3.
Used internally. Please refer to 7.8.2.
Used internally. Please refer to 7.8.2.
