Tab. 4: Peripherals; Tab. 5: Electrical, Mechanical And Environmental Specifications - Dave Embedded Systems AXEL LITE Hardware Manual

AXEL LITE Hardware Manual
Feature
Networks
CAN
SD/MMC
Serial buses
Audio
Timers
Debug
Feature
Supply Voltage
Active power
consumption
Dimensions
Operating
temperature
range
Connectors
(interrupts available)
Default: Fast Ethernet 10/100 Mbps with
integrated PHY (for Gigabit support please
contact our sales department)
2x CAN 2.0B ports (1x with integrated PHY)
up to 3x SD 3.0 /SDIO 3.0/MMC 4.x compliant
controllers
5x full-duplex SPI ports with four peripheral
chip selects
3x master and slave I²C interfaces
up to 3x I²S / SSI / AC97
Enhanced Periodic Interrupt Timer
General Purpose Timer
JTAG IEEE 1149.1 Test Access Port
CoreSight™ and Program Trace Macrocell
(PTM)
Single 3.3V input, voltage regulation on board
See section 8.3 - Power consumption
67.5mm x 43mm
Commercial: 0°C / +70°C
Industrial: -40°C / +85°C
SODIMM 204 pins

Tab. 5: Electrical, Mechanical and Environmental Specifications

Specifications

Tab. 4: Peripherals

Specifications
October, 2016
v. 0.9.5
Options
Options
15/63
