Dave Embedded Systems AXEL LITE Hardware Manual page 33

AXEL LITE Hardware Manual
Pin Pin Name
J2.117 HDMI_D0P
J2.119 HDMI_D1N
J2.121 HDMI_D1P
J2.123 HDMI_D2N
J2.125 HDMI_D2P
J2.127 HDMI_CEC_IN
J2.129 HDMI_HPD
J2.131 DGND
J2.133 LVDS0_CLK_N
J2.135 LVDS0_CLK_P
J2.137 LVDS0_TX0_N
J2.139 LVDS0_TX0_P
J2.141 LVDS0_TX1_N
J2.143 LVDS0_TX1_P
J2.145 LVDS0_TX2_N
J2.147 LVDS0_TX2_P
J2.149 LVDS0_TX3_N
J2.151 LVDS0_TX3_P
J2.153 DGND
J2.155 LVDS1_CLK_N
J2.157 LVDS1_CLK_P
J2.159 LVDS1_TX0_N
J2.161 LVDS1_TX0_P
J2.163 LVDS1_TX1_N
J2.165 LVDS1_TX1_P
J2.167 LVDS1_TX2_N
J2.169 LVDS1_TX2_P
J2.171 LVDS1_TX3_N
J2 – ODD [1-203]
Internal Connections
CPU.HDMI_D0P
CPU.HDMI_D1N
CPU.HDMI_D1P
CPU.HDMI_D2N
CPU.HDMI_D2P
CPU.HDMI_DDCCEC
CPU.HDMI_HPD
DGND
CPU.LVDS0_CLK_N
CPU.LVDS0_CLK_P
CPU.LVDS0_TX0_N
CPU.LVDS0_TX0_P
CPU.LVDS0_TX1_N
CPU.LVDS0_TX1_P
CPU.LVDS0_TX2_N
CPU.LVDS0_TX2_P
CPU.LVDS0_TX3_N
CPU.LVDS0_TX3_P
DGND
CPU.LVDS1_CLK_N
CPU.LVDS1_CLK_P
CPU.LVDS1_TX0_N
CPU.LVDS1_TX0_P
CPU.LVDS1_TX1_N
CPU.LVDS1_TX1_P
CPU.LVDS1_TX2_N
CPU.LVDS1_TX2_P
CPU.LVDS1_TX3_N
October, 2016
Ball/ Supply Type Voltage
pin # Group
K6
J3
J4
K3
K4
K2
K1
-
V4
V3
U2
U1
U4
U3
V2
V1
W2
W1
-
Y3
Y4
Y1
Y2
AA2
AA1
AB1
AB2
AA3
v. 0.9.5
Note
33/63
