(24) SATA LED(D10)
(25) Power Button(PWRBTN1)
Jumper List:
(1) RS485/RS422selection pin header (J485/422)

Table 2.1: RS485/RS422selection pin header (J485/422)

Function
RS485 (Default)
RS232
Table 2.2: AT/ATX Mode Selection (PSON1)
Function
AT Mode
ATX Mode (Default)
2.2

Connectors

2.2.1

CPU-System on chip(SOC1)

UTX-3117 User Manual
Setting
1 2 3
1 and 2
1 2 3
2 and 3
Setting
1 2 3
1 and 2
1 2 3
2 and 3
