2.2.15
SATA Signal Connector (SATA1)
Pin
Signal
1
GND
2
SATA0_Z_TX+
3
SATA0_Z_TX-
4
GND
5
SATA0_Z_RX-
2.2.16
USB 3.0 Connector(USB1)
2.2.17
USB 3.0 Connector(USB2)
Pin
Signal
1
+USBV1
2
USB_D0-
3
USB_D0+
4
GND
5
USB3X0_Z_RX-
6
USB3X0_Z_RX+
Pin
Signal
6
SATA0_Z_RX+
7
GND
8
x
9
x
6
SATA0_Z_RX+
Pin
Signal
7
GND
8
USB3X0_Z_TX-
9
USB3X0_Z_TX+
H1
GND_F1
H2
GND_F1
x
19
UTX-3117 User Manual
