  • Page 1 User Manual UNO-2271G V2 電腦 ® Intel Pocket-Size Gateway with 2 x GbE, 2 x USB 3.2, 1 x mPCIe, 1 x HDMI, 1 x eMMC...
  • Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.
  • Page 3 UNO2271GN2212304-T UNO2271GN2212305-T UNO2271GN2212306-T UNO2271GN2212307-T UNO2271GN2212308-T UNO2271GN2212309-T UNO2271GN2212310-T UNO2271GN2212311-T UNO2271GN2212312-T UNO2271GN2212313-T UNO2271GN2212314-T UNO2271GN2212315-T UNO2271GN2312301-T UNO2271GN2312302-T UNO2271GN2312303-T UNO2271GN2312304-T UNO2271GN2312305-T UNO2271GN2312306-T UNO2271GN2312307-T UNO2271GN2312308-T UNO2271GN2312309-T UNO2271GN2312310-T UNO2271GN2212401-T UNO2271GN2212402-T UNO2271GN2212403-T UNO2271GN2212404-T UNO2271GN2212405-T UNO2271GN2212406-T UNO2271GN2212407-T UNO2271GN2212408-T UNO2271GN2212409-T UNO2271GN2212410-T UNO2271GN2312401-T UNO2271GN2312402-T UNO2271GN2312403-T UNO2271GN2312404-T UNO2271GN2312405-T UNO2271GN2312406-T UNO2271GN2312407-T UNO2271GN2312408-T UNO2271GN2312409-T UNO2271GN2312410-T UNO2271GN2212501-T...
  • Page 4 Product Warranty (2 years) Advantech warrants the original purchaser that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products that have been repaired or altered by persons other than repair personnel authorized by Advantech, or products that have been subject to misuse, abuse, accident, or improper installation.
  • Page 5 This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This type of cable is available from Advantech. Please contact your local supplier for ordering information.
  • Page 6 Safety Precautions - Static Electricity Follow these simple precautions to protect yourself from harm and the products from damage. To avoid electrical shock, always disconnect the power from the PC chassis  before manual handling. Do not touch any components on the CPU card or other cards while the PC is powered on.
  • Page 7 This equipment is not suitable for use in locations where children are likely to be present. If the equipment is used in a manner not specified by the Advantech, the protec- tion provided by the equipment may be impaired. The equipment contains no user-serviceable parts. Do not open, Return to man- ufacturer for servicing.
  • Page 8 Ne jamais verser de liquide dans une ouverture. Cela pourrait provoquer un incendie ou un choc électrique. N'ouvrez jamais l'équipement. Pour des raisons de sécurité, l'équipement doit être ouvert uniquement par du personnel qualifié. Si l'une des situations suivantes se présente, faites vérifier l'équipement par le personnel de service: –...
  • Page 9 安全指示 請仔細閱讀此安全操作說明。 請妥善保存此用戶手冊供日後參考。 用濕抹布清洗設備前，請確認拔除電源線。請勿使用液體或去污噴霧劑清洗設 備。 對於使用電源線的設備，設備周圍必須有容易接觸到的電源插座。 請勿在潮濕環境中試用設備。 請在安裝前確保設備放置在可靠的平面上，意外摔落可能會導致設備損壞。 設備機殼的開孔適用於空氣對，從而防止設備過熱。請勿覆蓋開孔。 當您連接設備到電源插座前，請確認電源插座的電壓符合要求。 請將電源線佈置在人們不易絆倒的位置，請勿在電源線上覆蓋任何雜物。 請注意設備上所有的警告標示。 如果長時間不使用設備，請拔除與電源插座的連結，避免設備被超標的電壓波動 損壞。 請勿讓任何液體流入通風口，以免引起火灾或短路。 請勿自行打開設備。為了確保您的安全，請透過經認證的工程師來打開設備。 如遇下列情况，請由專業人員維修： 電源線或插頭損壞； 設備內部有液體流入； 設備曾暴露在過度潮濕環境中使用； 設備無法正常工作，或您無法透過用戶手冊來正常工作； 設備摔落或損壞； 設備有明顯外觀損； 請勿將設備儲存在超出建議溫度範圍的環境，即不要低於 -40°C（-40°F）或 高於 85°C（185°F），否則可能會造成設備損壞。 注意：若電池更換不正確，將有爆炸危險。因此，只可以使用製造商推薦的同一 種或者同等型號的電池進行替換。請按照製造商的指示處理舊電池。 根據 IEC 704‐1:1982 規定，操作員所在位置音量不可高於 70 分貝。 限制區域：請勿將設備安裝於限制區域使用。 免責聲明：請安全訓示符合 IEC 704‐1 要求。研華公司對其內容之準確性不承 擔任何法律責任。...
  • Page 10 UNO-2271G_V2 User Manual...

  • Page 11: Table Of Contents

    Extension Kit (Optional) ..............4 Dimensions ....................5 Figure 1.1 UNO-2271G V2 Dimensions ........5 Figure 1.2 UNO-2271G V2 Dimensions (with Optional Extension Kit) ................5 Figure 1.3 UNO-2271G V2 Dimensions (with Stack Extension Kit for iDoor)..............6 Chapter Hardware Functionality.......7 Introduction ....................
  • Page 12 3.4.3 Installing a 2nd Stack Extension Kit (UNO-2271G-RP1EA) ..23 Installing Internal Component ..............25 3.5.1 Installing miniPCIe Module ............25 3.5.2 Installing the M.2 B-Key Module on Extension Kit (UNO-2271G- RP1EA/UNO-2271G-RS2EA)............. 27 3.5.3 Installing the M.2 E-key Module on Extension Kit (UNO-2271G- RS2EA)..................

  • Page 13: Chapter 1 Overview

    Chapter Overview This chapter overviews specifica- tions for UNO-2271G V2.  Introduction  Safety Precautions  Accessories  Hardware Specifications  Dimensions...

  • Page 14: Introduction

    Introduction Advantech's new UNO-2 series serve as modular Integrated Edge Controllers. They provide configuration flexibility for customers seeking to cost effectively optimize their services. The new integrated Din-rail mounting kit is designed to be more ruggedized and user-friendly, making it a perfect fit for control cabinets.

  • Page 15: Packing List

    Packing List Please refer to below packing list: UNO-2271G V2  1 x plug-in block for power wiring  Simplified Chinese manual  Quick Start Guide  Warranty card  If anything is missing or damaged, contact your distributor or sales representative immediately.

  • Page 16: Environment

    Certification CE, FCC, UL, CCC, BSMI 1.4.6 Extension Kit (Optional) UNO-2271G V2 features a modularized design. Advantech offers two optional 2nd stack extension kits for users to expand the functionality using an Advantech iDoor module. Part number UNO-2271G-RP1EA Description 2nd stack extension kit to support POE PD, COM, M.2 B key Ports 1 x POE (802.3AT), 1 x COM...

  • Page 17: Dimensions

    Dimensions 100 x 70 x 130 mm (11.8 x 27.6 x39.3 in) Figure 1.1 UNO-2271G V2 Dimensions Figure 1.2 UNO-2271G V2 Dimensions (with Optional Extension Kit) UNO-2271G_V2 User Manual...
  • Page 18 Figure 1.3 UNO-2271G V2 Dimensions (with Stack Extension Kit for iDoor) UNO-2271G_V2 User Manual...

  • Page 19: Chapter 2 Hardware Functionality

    Chapter Hardware Functionality This chapter details setup instruc- tions for UNO-2271G V2’s hard- ware functions. It includes connecting peripherals and indi- cators.  Introduction  External I/O Connector  Internal I/O Connector  LED Indicators  Reset Buttons  Antenna Hole...

  • Page 20: Introduction

    The following diagram demonstrates the location of UNO-2271G V2’s motherboard and extension kit’s internal/external connectors. 2.1.1 Base Unit's Internal Connectors Figure 2.1 Diagram of Connector Locations on UNO-2271G V2 (Top Side) Figure 2.2 Diagram of Key Components Location on UNO-2271G V2 (Bottom Side) UNO-2271G_V2 User Manual...

  • Page 21: Base Unit's External I/O Connector

    Power Connector external UNO-2271G V2 comes with a Phoenix connector that carries 10 - 30 V power input, and features reversed wiring protection. Therefore, the system will not accrue damage from reversed polarity of ground lines and power lines. (Please refer to User Manual - Appendix A.1 for pin assignments)

  • Page 22: Expansion Kit's Internal Connectors (Optional)

    2.1.2.3 USB Connector UNO-2271G V2 features 2 x USB ports for Rev. 3.2 specifications. The USB connec- tors support plug-and-play and hot-swap-ping functionality for external devices. Addi- tionally, this can be enabled/disabled in the BIOS menu. (Please refer to User Manual- Appendix A.3 for pin assignments.)
  • Page 23 Figure 2.6 Locations Internal I/O Connectors/Switches for UNO-2271G-RS2EA (Bottom Side) (Optional) Figure 2.7 Locations Internal I/O Connectors/Switches for UNO-2271G-RP1EA (Top Side) (Optional) UNO-2271G_V2 User Manual...
  • Page 24 Figure 2.8 Locations Internal I/O Connectors/Switches for UNO-2271G-RP1EA (Bottom Side) (Optional) Table 2.2: Internal Connectors and Jumper Switches Label Function COM Port Terminal Connector (RS232/422/485) CN37 LAN Signal Connector M.2 B key for 2242/3042/3052 Connector CN40 M.2 E key for 2230 Connector SIM card slot SW8/SW1 COM port setting switch...

  • Page 25: Others

    2.1.3.5 COM Connector The second stack extension kit of UNO-2271G V2 provides has 2 COM RS232/422/ 485 ports of terminal block type. They offer transmission speeds of 50 ~115.2 kbps. The default mode for both COM ports (COM1&COM2) is RS-232 Mode. Settings can be adjusted via an on-board switch (SW1).
  • Page 26 UNO-2271G_V2 User Manual...

  • Page 27: Chapter 3 Initial Setup

    Chapter Initial Setup This chapter explains how to Ini- tialize the UNO-2271G V2.  Chassis Grounding  Connecting Power  Open and Close Bottom Cover  Installing a 2nd Stack Extension  Installing internal component  Antenna Installation (Optional)  BIOS Settings...

  • Page 28: Chassis Grounding

    Chassis Grounding The UNO-2271G V2 provides good EMI protection and a stable grounding base and there is an easy-to-connect chassis grounding point for this purpose. Figure 3.1 Chassis Grounding Connection Diagram Use the grounding cable (16 AWG) from the accessory bag to connect the chassis ground with the Earth ground.

  • Page 29: Open And Close Bottom Cover

    Open and Close Bottom Cover The steps for opening and closing the bottom cover of UNO-2271G V2 are demon- strated below. To open the bottom cover: Remove the 5 screws from the back cove and lift it off. To close the bottom cover: Put the bottom cover onto the UNO-2271G V2 chas- sis.

  • Page 30: Installing A 2Nd Stack Extension Kit

    Affix the bottom cover with 5 screws. Installing a 2nd Stack Extension Kit 3.4.1 Installing a 2nd Stack Extension Kit (UNO-2271G-EKBE) Remove the 5 screws and lift the bottom cover. UNO-2271G_V2 User Manual...
  • Page 31 Lock the 2nd stack bracket with 5 screws. Lock the bracket and extension module with 2 screws. UNO-2271G_V2 User Manual...
  • Page 32 Lock the bottom cover with 3 screws and 3 rubbers. UNO-2271G_V2 User Manual...

  • Page 33: Installing A 2Nd Stack Extension Kit (Uno-2271G-Rs2Ea)

    3.4.2 Installing a 2nd Stack Extension Kit (UNO-2271G-RS2EA) Remove 5 screws and lift the bottom cover. UNO-2271G_V2 User Manual...
  • Page 34 Connect to the BTB connector and fix with 3 screws. UNO-2271G_V2 User Manual...

  • Page 35: Installing A 2Nd Stack Extension Kit (Uno-2271G-Rp1Ea)

    Affix the bottom cover with 3 screws. 3.4.3 Installing a 2nd Stack Extension Kit (UNO-2271G-RP1EA) Remove 5 screws and lift the bottom cover. UNO-2271G_V2 User Manual...
  • Page 36 Connector to BTB Connector and lock the bottom with 3 screws. UNO-2271G_V2 User Manual...

  • Page 37: Installing Internal Component

    Lock the bottom cover with 3 screws. Installing Internal Component 3.5.1 Installing miniPCIe Module Remove the 5 screws from the back cover of UNO. UNO-2271G_V2 User Manual...
  • Page 38 Insert the mPCIE card at the location: “CN3”. Secure it with the provided screws. UNO-2271G_V2 User Manual...

  • Page 39: Installing The M.2 B-Key Module On Extension Kit (Uno-2271G- Rp1Ea/Uno-2271G-Rs2Ea)

    3.5.2 Installing the M.2 B-Key Module on Extension Kit (UNO- 2271G-RP1EA/UNO-2271G-RS2EA) Installing M.2 3042 card Remove the pre-installed screw. Insert the M.2 3042 card at the location of “CN2” and lock the screw. UNO-2271G_V2 User Manual...
  • Page 40 Installing M.2 3052 card Remove the pre-installed screw. Insert the M.2 3042 card at the location of “CN2” and lock the screw. UNO-2271G_V2 User Manual...

  • Page 41: Installing The M.2 E-Key Module On Extension Kit (Uno-2271G- Rs2Ea)

    3.5.3 Installing the M.2 E-key Module on Extension Kit (UNO-2271G- RS2EA) Installing M.2 2230 card Remove the pre-installed screw. UNO-2271G_V2 User Manual...

  • Page 42: Antenna Installation (Optional)

    Insert the M.2 2230 card at the location of “CN40” and lock the screw. Antenna Installation (Optional) UNO-2271G V2 reserves pre-cut antenna hole for wireless connection. Follow the steps below for installation the SMA cable and antenna. Remove the 5 screws from the back cover of UNO.

  • Page 43: Bios Setting

    Remove the plug of the antenna’s pre-cut hole(s) on the rear panel. Assemble SMA cable on the pre-cut hole. Assemble the antenna on the SMA connector of the antenna cable. BIOS Setting With the BIOS Setup program, you can modify BIOS settings and control the special features of your computer.
  • Page 44 UNO-2271G_V2 User Manual...

  • Page 45: Appendix A System Settings/Pin Assignments

    Appendix System Settings/Pin Assignments...

  • Page 46: Power Connector (Dcin1)

    Power Connector (DCIN1) Table A.1: Power Connector Pin Assignments Signal Description Power IN V+ 10 - 30 V Power IN V- (GND) LAN: Ethernet Connector (LAN1) Table A.2: Ethernet Connector Pin Assignments RJ45 Pin Signal Description In BASE-T: Media Dependent Interface[0]: ...

  • Page 47: Usb Connector (Usb1)

    USB Connector (USB1) A.3.1 USB 3.0 Connector Table A.3: USB 3.0 Connector Pin Assignments Signal Name Description VBUS Power USB 2.0 differential pair Ground for power return StdA_SSRX- SuperSpeed receiver differential pair StdA_SSRX+ GND_DRIAN Ground for signal return StdA_SSTX- SuperSpeed transmitter differential pair StdA_SSTX+ UNO-2271G_V2 User Manual...

  • Page 48: Hdmi Connector (Cn1)

    HDMI Connector (CN1) Table A.4: Display Port Adapter Cable Pin Assignments Signal Name TMDS1_a_P0 TMDS1_a_N0 TMDS1_a_P1 TMDS1_a_N1 TMDS1_a_P2 TMDS1_a_N2 TMDS1_CLK_a_P TMDS1_CLK_a_N TMDS1_DDCCLK TMDS1_DDCDAT TMDS1_HPD UNO-2271G_V2 User Manual...

  • Page 49: M.2 B-Key Connector (Cn2)

    M.2 B-key Connector (CN2) Table A.5: M.2 B Key Connector Pin Assignments Signal Name Signal Name M2_SATA1_DET +V3.3_M2 +V3.3_M2 M2_LTE_PWR_OFF# M2_LTE_USB_DP M2_LTE_W1_DISABLE_N M2_LTE_USB_DN +V3.3_M2 Mechanical notch B Mechanical notch B Mechanical notch B Mechanical notch B Mechanical notch B Mechanical notch B Mechanical notch B Mechanical notch B WAKE_ON_WAN#...

  • Page 50: M.2 E-Key Connector (Cn40)

    Table A.5: M.2 B Key Connector Pin Assignments +V3.3_M2 +V3.3_M2 +V3.3_M2 M.2 E-Key Connector (CN40) Table A.6: M.2 E key Connector Pin Assignments Signal Name Signal Name +V3.3SB_M2E M2E_USB_D+ +V3.3SB_M2E M2E_USB_D- M2E_LED_1# M2E_LED_2# Mechanical notch E Mechanical notch E Mechanical notch E Mechanical notch E Mechanical notch E Mechanical notch E...

  • Page 51: Mpcie Connector (Mini1)

    Table A.6: M.2 E key Connector Pin Assignments M2E_I2C_DATA M2E_I2C_CLK M2E_ALERT# M2E_PERST1# M2E_CLKREQ1# M2E_PEWAKE1# +V3.3SB_M2E +V3.3SB_M2E mPCIe Connector (MINI1) Table A.7: mPCIe Connector Pin Assignments Signal Name Signal Name PCIE_WAKE# +V3.3_MINI +V1.5 PCIEX1_CLKREQ0# CLK100M_PCIEX1_D0- CLK100M_PCIEX1_D0+ WIFI_DISABLE# MINI_PLTRST# SATA0_RX+ +V3.3_MINI SATA0_RX- +V1.5 SATA0_TX- SATA0_TX+...

  • Page 52: Com Port Rs232/422/485 Settings

    Table A.7: mPCIe Connector Pin Assignments MPCIE_PWRSEL +V1.5 MSATA#_z_PCIE_SEL +V3.3_MINI COM Port RS232/422/485 Settings The default setting for the COM port is RS-232. This can be changed to RS-422 or RS-485 modes can be configured by adjusting switch on the motherboard. Table A.8: COM Connector Pin Assignments COM1 Mode Signal Name...

  • Page 53: Rs232/422/485 Setting (Sw8/Sw1)

    A.8.1 RS232/422/485 Setting (SW8/SW1) SW1 Default Description This switch is used to select RS232/422/485 mode setting Default RS232 mode Bit 1 ON RS232 Mode Bit 2,3,4,5,6,7,8,9,10 OFF Bit 2,4,5 ON COM1 RS485 Mode Bit 1,3,6,7,8,9,10 OFF Bit 1,2,4,5 ON RS422 Mode Bit 3,6,7,8,9,10 OFF Bit 6 ON RS232 Mode...

  • Page 54: Com Port Rs422/485 Termination Resistor Setting

    A.8.2 COM Port RS422/485 Termination Resistor Setting Termination Resistor Setting This switch is used to select Termination Resistor (120 ohm) Description for long distance transmission or device matching. Default Bit3 off & Bit8 off COM1 Bit3 on COM2 Bit8 on AT/ATX Setting (PSON1) PSON1 can be used for AT/ATX setting.

  • Page 55: Board To Board Connector (Reserved For Expansion) (Cn13)

    A.10 Board to Board Connector (Reserved for Expansion) (CN13) Table A.9: Expansion Board to Board Connector Pin Assignments Signal Name Signal Name ESPI_CLK ESPI_ALERT0# ESPI_IO0 ESPI_IO1 ESPI_IO2 ESPI_IO3 ESPI_CS0# ESPI_RST0# PMC_SUSCLK PMC_SLP_S3# GP_H00 PCIE_WAKE# PLTRST_M.2# M2B1_CLKREQ2# USB2_P0+ USB2_P0- USB2_P4+ USB2_P4- CLK100M_M2E1_D2+ CLK100M_M2E1_D2- PCIE4_TX+...

  • Page 56: Tpm 2.0 Bios Setting

    The UNO-2271G V2 systems support TPM 2.0 functionality. This can be enabled or disabled in the BIOS menu by following the instructions provided below: Power on the UNO-2271G V2 system and press “Delete” to enter the BIOS con- figuration menu.
  • Page 57 Then select the “Security Device Support” item. Choose “enable/disable” to enable or disable the TPM 2.0 function (The default setting is to disable this function) UNO-2271G_V2 User Manual...

  • Page 58: Cpu Turbo Mode Bios Setting

    A.12 CPU Turbo Mode BIOS Setting The UNO-2271G V2 systems supports CPU Turbo mode. This can be enabled or dis- abled in the BIOS menu by following the instructions: Power on the UNO-2271G V2 system and press “Delete” to enter the BIOS con- figuration menu.

  • Page 59: Tco Setting For Watchdog Os Support

    A.13 TCO Setting for Watchdog OS support The UNO-2271G V2 systems supports Watchdog timer. TCO can be enabled or dis- abled in the BIOS menu by following the instructions: TCO enable for Linux OS use (BIOS default). TCO disable for Windows OS use.
  • Page 60 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2022...
