Summary of Contents for Advantech WOP-2000G
Page 1
Hardware / 硬件相关 / 硬體相關 Dimensions / 外观尺寸 / 外觀尺寸 29mm 98.6mm STATUS 1 For more information on this and other Advantech products, please visit our website at: http://www.advantech.com http://www.advantech.com/eplatform For technical support and service, please visit our support website at: http://support.advantech.com...
Page 3
Screw each fixing screw until the bezel corner gets in contact with the panel. 使用固定螺丝固定时请注意不要锁太紧,以避免压迫造成其他问题。 使用固定螺絲固定時請注意不要鎖太緊,以避免壓迫造成其他問題。 Dispose of Batteries / 电池处置 / 電池處置 可充式電池/ 可充式电池 VL 2330 MATSUSHITA/PANASONIC 3V 50mAh Vanadium Lithium Rechargeable Battery type Dispose of batteries according to local regulations. 废弃电池的处置请依据使用者所在地区对废弃电池处置方式办理。 廢棄電池的處置請依據使用者所在地區之規範辦理廢棄電池處置方式。 WOP-2000G Installation Guide 3...
Page 4
電池電量100%時,在斷電停機狀態下能保持五個月(一般環境),請在保持時間內充電72小時,因電量不足的情況下會 造成電池記憶體的資料不正確。(Battery SW必須先調整至ON) Battery SW • When switching from OFF to ON, the WOP-2000G needs to reset RTC and clear recorded data. 当开关从OFF至ON时的位置时,需要重新设定万年历和清除纪录数据。 當開關從OFF至ON時的位置時,需要重新設定萬年曆和清除紀錄資料。 • Turn the switch to OFF when the machine is not going to run for a long time to avoid low battery voltage and short battery life time.
Page 6
運行模式;使用者執行應用程序。 Setup mode. 设置模式。 設置模式。 Rescue Mode is running. 救援模式正在运行。 救援模式正在運作。 Boot Loader is waiting for command. 初始模式。 初始模式。 Run mode (Battery low). 运行模式(电池电力不足或电压过低)。 運行模式(電池電力不足或電壓過低)。 The user application and(or) the OS are being updated. 用户应用程序和(或)软件更新。 使用者應用程序和(或)軟體更新/。 6 WOP-2000G Installation Guide...
Page 7
Mode Description (模式/模式) (说明/說明) Rescue Mode STEP1. Press the switch and turn on the power of the WOP-2000G. STEP2. Keep pressing for six seconds until LED signal sequence shows. (救援模式) LED signal sequence / LED灯号显示顺序 / LED燈號顯示順序 (救援模式) STEP3. Release the switch.
