    Chapter Introduction This Chapter briefly introduces the UTX-3115 product.
  • Page 14: Overview

    Since low power and small Intel CPUs have come quite a long way, UTX-3115 is designed with the latest Intel SOC which has lower power consumption but with higher CPU performance. The benefit for cus- tomer in UTX-3000 is quiet operation and wide temperature system and is open to a large range of applications and markets.
  • Page 15: System Configuration

    System Configuration The following diagram is a block drawing of the UTX-3115. Chrontel 7511 LVDS 48-bit LVDS DDR3L 1333 MHz SO-DIMM Channel A micro HDMI DDR3L 1333 MHz SO-DIMM Channel B GbE LAN1: PCIe x1 Intel I210AT HDMI Intel Atom...
  • Page 16 UTX-3115 User Manual...
  • Page 17: Chapter 2 Hardware Description

    Chapter Hardware Description This Chapter describes the hard- ware features of the UTX-3115.
  • Page 18: General Specifications

    System Dimensions: 138.5 x 35.98 x 116.4 mm (5.5" x 1.4" x 4.6") 138.50 116.40  Carton Dimensions: 255 (L) X 235 (W) X 160 (H) mm  Gross Weight: 2.0 kg  Net Weight: 1.8 kg UTX-3115 User Manual...
  • Page 19: Chapter 3 Design Requirements

    Chapter Design Requirements This Chapter describes the design requirements of the UTX-3115.
  • Page 20: Environmental Specifications

     Relative Humidity: 40 ~ 95% RH (Non-condensed)  Safety  CE / UL  FCC class B approved for USA, Canada, and EU Vibration:  With SSD: 3Grms, 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis UTX-3115 User Manual...
  • Page 21 UTX-3115 User Manual...
  • Page 22 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2014...
