- Technical characteristics

Technical characteristics

1 - Main characteristics

Certain options can modify the machine's operating characteristics and its associated safety. If your
machine was originally delivered with options fitted, replacing a safety component associated with a
particular options not require any particular precautions other than those associated with the installation
itself (static test).
Otherwise, it is essential to follow the manufacturer's recommendations below :
• Installation by authorised HAULOTTE® personnel only.
• Update the manufacturer's identification plate.
• Have stability tests carried out by a certified agency/competent person.
• Ensure label compliance.
HAULOTTE® has a continuous improvement policy in place for its product range ; Given this policy, The
Company reserves the right to modify their product technical characteristics without notice.
The hand and feet vibration and noise level values indicated in the technical characteristics tables are
obtained in the following conditions :
• The maximum quadratic mean value weighted as an acceleration frequency and the total value of the
vibrations to which the hand-arm system is exposed have been measured on the products by simulating
a cycle representative of normal use. The values meet the requirements of the 2006/42/CE machine
directive.
• For electric machines, the sound power level is measured at the drive station under the conditions
described by the 2006/42/CE machine directive.
• For machines equipped with internal combustion engines, the noise level guarantees ( LWA displayed
on the product) and is measured in accordance with the method and the conditions described in
Appendix III, Part B, Method 1 and 0 of the 2000/14/CE European directive.
Maximum authorised tilt : Machine in transport position (Turntable pinned on the chassis, arm folded,
boom retracted and lowered, jib below horizontal).
For HA120PX - Technical characteristics
Length of machine in stowed position
Overall width of machine
Machine height
Maximum ground clearance
Transport height
Transport length
Maximum work height
Maximum platform height
Maximum drift
Maximum work radius
Turntable rotation
Boom rotation angle
Jib working range
Platform length
Platform width
Platform rotation angle
2420332370
Machine
Characteristics
E06.11
HA120PX
Metric
5,51 m
1,90 m
2,27 m
0,26 m
2,27 m
5,51 m
12,15 m
10,15 m
6,60 m
6,10 m
350 °
+75° / - 4°
140 °(+70° / - 70°)
1,50 m
0,80 m
180 °(+90° / -90°)
Imperial
(18 ft1 in)
(6 ft3 in)
(7 ft5 in)
(0 ft11 in)
(7 ft5 in)
(18 ft1 in)
(39 ft10 in)
(33 ft4 in)
(21 ft8 in)
(20 ft0 in)
(4 ft11 in)
(2 ft7 in)
EN 93
