Chassis Tilt - Haulotte HA16X Operator's Manual

Engine-powered articulated lifts, 12 - 26 m
D
- Operating principle
2.9 -

CHASSIS TILT

For HA16X
If the machine is located on a slope exceeding the authorized limit, the operator is warned by
the slope sensor indicator on the platform control box and the buzzer.
Driving is cut (If the machine is unfolded).
To restore the drive function, only movements allowing the machine to be stowed are
permitted :
• Telescope in.
• Lowering the boom to return to a horizontal position.
• Lowering the arm.
For HA120PX - HA16PX - HA18PX - HA16SPX - HA18SPX -
If the machine is located on a slope exceeding the authorized limit, the operator is warned by
the slope sensor indicator on the platform control box and the buzzer.
Driving is cut (If the machine is unfolded).
To restore the drive function, only movements allowing the machine to be stowed are
permitted :
• Telescope in.
• Lowering the boom to return to a horizontal position.
• Lowering the arm.
• Lowering the jib until it is below horizontal position.
For HA20PX - HA260PX
If the machine is located on a slope exceeding the authorized limit, the operator is warned by
the slope sensor indicator on the platform control box and the buzzer.
Driving is cut (If the machine is unfolded).
To restore the drive function, only movements allowing the machine to be stowed are
permitted :
• Telescope in.
• Boom lowering to return to a horizontal position.
• Lowering the arm.
• Lowering the jib until it is below horizontal position.
2420332370 E06.11 EN 63
