- Operating principle
2.4 -

LENGTH AND ANGLE SENSORS

For reasons of stability and work area management, the boom is equipped with length and
angle sensors.
These length and angle sensors transmit data allowing the calculator to manage automatic
operation of combined movements.
Operating rules for HA260PX
In certain configurations :
• When a control is activated to lower the arm, the system organises the combination of movements
required to lower the boom.
• When a control is activated to lower the boom, the system organises the combination of movements
required for boom telescope.
2.5 -

ON-BOARD ELECTRONICS

The machines are equipped with a specific calculator configured for the machine's
functionalities.
Do not interchange the calculator between machines.

2.6 - DETECTION OF INTERNAL FAULT

N.B.-:-T
HE PRESENCE OF THIS DEVICE DEPENDS ON THE MACHINE CONFIGURATION
The defect indicator flashs to indicate an internal malfunction.
The machine switches to downgraded mode.
Certain movements can be limited or forbidden to preserve the operator's safety.
2.7 -

AUTOMATIC ENGINE CUT-OUT

The engine automatically cuts out in the following conditions :
• The alternator is not functioning.
• Engine temperature is too high.
• Oil pressure is too low.
• A machine malfunction is detected.
For machines fitted with(HA260PX ) :
• The platform has gone outside the work area.

2.8 - LOAD LIMITING IN THE PLATFORM (IF FITTED)

If the platform load exceeds the maximum authorized load, no movement is
possible from the platform control box.
The platform overload indicator and the buzzer warn the operator that the
overload condition exists..
To return the machine to normal operation remove some weight from the platform.
