The Graph user interface

The color display offers easy monitoring and programming. It can
be confi gured to show information from any Power Focus within a
cell. The display is fully confi gurable - the picture below shows only
one example.
Job no.
Channel
number
in the cell
Press View if you want
to see
- tightening traces
- statistics
- events
Pset (P) or Multi-
stage (M) number
7
Batch count
no. and
(batch size)
Press Browse if you
want to change the
view of the lower
right window, to see
for example the no.
of tightenings left in a
batch
