Atlas Copco Power Focus 4000 Graph Quick Manual page 35

E460 FieldBus Type Mailbox
Message Fault
E461 FieldBus Type Gen
Com Fault
E462 FieldBus Mailbox Mes-
sage Fault
E463 FieldBus Gen Com Fault
E464 FieldBus Hardware
Fault
E465 FieldBus Dip switch Error
E466 FieldBus Offl ine
E467 FieldBus Confi guration
Fault
E468 FieldBus Hardware
Mismatch
E469 FieldBus Init Error
E470 FieldBus PCP error
E471 Fieldbus claim area fai-
led, lost one message
E472 Fieldbus release area
timeout
E473 Fieldbus communica-
tion buffer alarm
E474 Fieldbus monitor buffer
alarm
E475 Fieldbus PsetID mis-
match selector lifted
socket
E480 Channel ID not valid
-
-
-
-
Yes The FieldBus module is broken and
has to be replaced.
- The software tries to confi gure the value
of node address or baudrate but the
address switch on the FieldBus module
is not in the right position to enable soft-
ware setting. Set switches in the right
position, then turn on the power.
- The FieldBus went from Online to
Offl ine. This is just a warning.
-
- The FieldBus module installed in PF 3000
is not the same FieldBus type as confi gu-
red with TTPF . Change FieldBus module
or confi guration to get a match.
- RBU did not respond to command
from PF .
-
One packet lost.
Release area command timed out.
Communication buffer full. Decrease
fi eldbus update timer.
Fieldbus monitor buffer full. Turn off
fi eldbus monitor mode.
Fieldbus selected Pset does not fi le
the lifted socket.
Yes The channel ID confi gured is not within
the limits permitted. The channel ID
must confi gured between 1 and 20.
35
