E131 Tool Disconnected
E132 Wrong tool start input
settingt
E133 Tool locked by ToolsTalk
E134 MC Motortuning failure
E136 Rundown prohibited due
to batch locked
E137 The tool is locked by the
fi eld bus.caused the
tightening to be aborted
E138 Wrong tool start input
source
E139 Tool locked via Open
protocol
E140 Insert user ID card to
release tool
E141 Tool locked during
work order
E145 Tool locked by Timer
enable tool
E147 Tool locked by click
wrench Pset
E149 Tool locked, disable
loosening at OK
E150 Job client does not
respond
E151 Job in OFF mode
Yes This error indicates that the tool is not
connected to the controller or that the
tool cable has been damaged.
Yes 1) Check if the remote start wiring in
the PF is correctly set in accordance
to the settings in the Confi guration
parameters (C220).
2) Check if the tool trigger is con-
stantly pressed or if there is some
malfunction in the tool.
- The tool is locked by Tools Talk.
- The target signal is active in the drive
though the tightening has been acknow-
ledged by the CC-card.
- This error is displayed if the function lock
at batch OK is enabled and when the
batch is completed. The tool can only be
unlocked via a digital input.
- The tool is locked by the fi eld bus.caused
the tightening to be aborted
- It is only possible to start the tool from
the selected tool start select source.
- The tool is locked via Open protocol.
- The tool is locked, the user must
insert his ID card in the card reader to
release the tool.
Multiple identifi ers; tool is locked during
work order. Unlock will follow upon
receiving correct identifi ers
The tool is locked by digital "timer
enable tool"
A click wrench Pset is in use. For more
information see section Sub informa-
tion for event codes.
- "Disable loosning at OK" has locked the
tool for loosening
- When running a Cell Job, this error is
displayed by the job master when one of
the job members does not respond.
- It is not possible to select a new job,
the PF3000 is in Job Off mode.
