Setting up the normal two-stage tightening

Torque Control / Angle Monitoring – Two Stage
To quickly get started, either
1) make the basic settings using AutoSet
a) On the Compact, this is done by i) pressing the "arrow" button, ii) confi rming by
pressing Enter, iii) entering the fi nal torque target with the '+' and '-' buttons, and iv)
confi rming with the Enter button
b) On the Graph, the fi nal torque target for AutoSet is entered under the menu item
Pset -> AutoSet
In both cases, you then just make tightenings on the desired joint until the AutoSet lamp
goes out
2) or you use QuickProg in ToolsTalk PF or on the Graph (selecting Pset -> Quick prog) if
you already have an idea of the joint hardness
10
