Atlas Copco Power Focus 4000 Graph Quick Manual page 39

E824 Cycle abort timeout
E831 Autoset wrong angle
E833 Autoset tight NOK
result
E834 Autoset rejected Pset
in CCW direction
E840 Feature Not Available In
Software Revision
E841 SW function Not Availa-
ble for this tool type
E851 Connection with Tools
Net server lost
E856 Router unreachable
E857 Reboot needed before
changes take effect
E858 IP address already
in use
E859 IP address collision
E862 Ethernet overload Error
- No tightening result was received
from the drive before the Cycle abort
timeout. The Cycle Abort timer is
confi gurable in the Pset.
- Autoset could not be executed,
the angle results of the tightening
performed were null.
- The Autoset could not be executed,
four NOK tightenings were performed.
- The Autoset was not allowed by the
PF3000 for this Pset because the Pset
was confi gured in the CCW direction.
Auto set is only permitted on CW Pset.
This error is displayed if an attempt is
made to run multistage with a bronze
version, or handle a Pset with a Pset
ID larger than the max number of Pset
(larger than 64 in a bronze version
or larger than 250 in a silver or gold
version).
The software function is not availbale
for this tool type.
- The connection with the ToolsNet ser-
ver was lost, the PF3000 is trying to
reconnect. The Tools Net server might
be down or it might be an Ethernet
cable problem.
The router programmed in the confi -
guration setting could not be reached.
Check the network confi guration and
in particularly the sub net mask and
the default router.
The confi guration changes will not take
effect before a system reboot.
Yes The IP address of this PF3000 is
already in use by another system.
- Another system attempts to use the
same IP address as this PF3000.
The Ethernet driver of the PF3000 is swit-
ched off due to an overloaded network.
39
