Configuration - Atlas Copco Power Focus 4000 Graph Quick Manual

E240 Password Incorrect
Input Source
E250 Maxtime for fi rst tighten-
ing run out (job)
E251 Maxtime to complete
job run out
E300-E399: Statistical errors
E333 Not allowed subscription
E334 No statistic available for
this Pset
E335 Not enough data
E336 Mem alloc fail
E340 Xucl tq
E341 Xlcl tq
E342 Rucl tq
E343 Rlcl tq
E344 Cp tq
E345 Cpk tq
E346 7inc x tq
E347 7dec x tq
E348 7inc x r
- The password is entered from an
invalid source according to the
confi guration.
- This message is displayed and the job
is terminated if the fi rst tightening is not
performed within the specifi ed time.
- This message is displayed and the job
is terminated if the job is not completed
within the specifi ed time.
- The requested statistic subscription is
not allowed. For example it is not allowed
to set an angle statistic subscription
for a Pset using only the torque control
strategy.
- The Pset strategy is not suitable to
calculate statistics (no strategy is chosen,
DS control)
- Not enough data were available to
calculate the statistic control limits.
- It was not possible to allocate enough
memory for the statistic subscription.
- The last subgroup mean torque value is
larger than the upper control limit.
- The last subgroup mean torque value is
lower than the lower control limit.
- The last subgroup range torque value
is larger than the upper control limit.
- The last subgroup range torque value
is lower than the lower control limit.
- The torque Cp is lower than 2.
- The torque Cpk is lower than 1.33.
Trend deviation alarm – the subgroup
torque mean value has increased 7
times in a row
Trend deviation alarm – the subgroup
torque mean value has decreased 7
times in a row
Trend deviation alarm – the subgroup
torque range has increased 7 times
in a row
30
