POWER FOCUS
QUICK GUIDE
SAFETY INSTRUCTIONS
When using electric products, basic precautions should be followed:
❑ THIS EQUIPMENT MUST BE EARTH GROUNDED
❑ Always disconnect the equipment from the mains, by pulling the
plug, before opening it for installation, service etc
❑ Do not use this product near water
