Printed Matter No. 9839 0527 01
Publication Date 2025-04-10
Valid for Version No. 2.0.2
MT Focus 6000
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
MT Focus 6000
8432085100
WARNING
Control and drive unit
Configuration Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Atlas Copco MT Focus 6000
Summary of Contents for Atlas Copco MT Focus 6000
- Page 1 MT Focus 6000 Printed Matter No. 9839 0527 01 Control and drive unit Publication Date 2025-04-10 Valid for Version No. 2.0.2 Configuration Manual MT Focus 6000 8432085100 WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.
-
Page 2: Table Of Contents
Multiple result view ................ 9 Tightening ....................... 10 Measurement.................... 10 Batch sequence .................... 11 Import/Export via USB .................. 11 Configuration .................... 12 Logging in and out of the controller .............. 15 Login/Reboot menu .................. 15 Shortcuts...................... 15 Icons ....................... 16 © Atlas Copco Industrial Technique AB - 9839 0527 01... -
Page 3: Liability
Ensure that the joint conditions have not changed due to events of influence. ■ Be done after initial installation, maintenance or repair of the equipment. ■ Occur at least once per shift or at another suitable frequency. © Atlas Copco Industrial Technique AB - 9839 0527 01... -
Page 4: Configuration Overview
In some cases you can use the back button to cancel a selection. OK button Press the OK button to confirm a selection. Hold the OK button to open the lo- gin/reboot menu. © Atlas Copco Industrial Technique AB - 9839 0527 01... -
Page 5: User Interface
MT Focus 6000 Configuration Overview User interface Results Tightening Batch sequence Import/Export via USB Configuration © Atlas Copco Industrial Technique AB - 9839 0527 01... -
Page 6: Connectors
Vacuum pump: A vacuum can be connected through VP port. ■ Single USB flash drive: A USB flash drive can be inserted into the USB Host port. ■ USB hub: © Atlas Copco Industrial Technique AB - 9839 0527 01... - Page 7 Do not connect more than one USB flash drive, because only one USB flash drive can be detected by the MTF 6000. The total maximum current of the connected devices is 900 mA. © Atlas Copco Industrial Technique AB - 9839 0527 01...
-
Page 8: Settings
Red - failed. ■ Peak torque for each step. ■ Angle for each step. ■ Time for each step. ■ Max. peak torque of the tightening. ■ Total angle. ■ Total time. © Atlas Copco Industrial Technique AB - 9839 0527 01... -
Page 9: Torque/Angle Graph
Verification progress count: x/y to display current progress. if no verification size is set the controller will display an infinity symbol. ■ Live reference torque. Multiple result view The multiple result view is a summary of all the results in the verification. © Atlas Copco Industrial Technique AB - 9839 0527 01... -
Page 10: Tightening
QA controllers measurement results. The selected verification will be active until the verification sequence is completed and then you can choose a new verification pro- gram. © Atlas Copco Industrial Technique AB - 9839 0527 01... -
Page 11: Batch Sequence
Increases/decreases one step in the batch sequence Increment/decrement Batch Increases/decreases the progress of the batch counter. Import/Export via USB Data can be exported or imported to/from a connected USB flash drive. © Atlas Copco Industrial Technique AB - 9839 0527 01... -
Page 12: Configuration
Licenses from third party. Log out Logs out user, only available if a user is logged in. Control window (Licensed feature) Settings to view and edit the transducer and verifica- tion configurations. © Atlas Copco Industrial Technique AB - 9839 0527 01... - Page 13 Press OK button to toggle if the controller should set the internal clock to synchronize with the ToolsNet server or not. QA Supervisor (QAS) configuration Parameter Description Press OK button to toggle between: ■ Enabled ■ Disabled © Atlas Copco Industrial Technique AB - 9839 0527 01...
- Page 14 Verify CMK - The verification result will only look at the final CMK value to decide if the verification is OK or NOK. Verification size Number of measurements in the test. © Atlas Copco Industrial Technique AB - 9839 0527 01...
-
Page 15: Logging In And Out Of The Controller
UP = Select Pset list ■ Step view UP = Select Pset list (if the top menu of step result is reached) ■ Graph view UP = Select Pset list © Atlas Copco Industrial Technique AB - 9839 0527 01... -
Page 16: Icons
Controller is not connected to ToolsNet 8 USB Sync connection is active Controller is connected to QA Supervisor Controller is not connected to QA Supervisor An information/event popup is active but minimized © Atlas Copco Industrial Technique AB - 9839 0527 01... - Page 17 MT Focus 6000 Settings Ongoing active measurement Battery power 90 - 100 % Battery power 50 - 89 % Battery power 21-49 % Battery power <=20 % Success/Complete/Done Information Warning Error © Atlas Copco Industrial Technique AB - 9839 0527 01...
- Page 20 Original instructions Atlas Copco Industrial © Copyright 2025, Atlas Copco Industrial Technique AB. All rights reserved. Technique AB Any unauthorized use or copying of the contents or part thereof is prohibited. This applies in particular to trademarks, model denominations, part numbers SE-10523 STOCKHOLM and drawings.
