Power Connector

The power connector,
Table 3-2 summarizes the power connector pinout. If you do not use the
power supply provided with your EZ-KIT Lite board, replace it with one
that has the connections shown in
Table 3-2. Power Connection
Terminal
Center pin
Outer ring

European Power Supply Connections

Table 3-3 summarizes the European power supply specifications.
Table 3-3. European Power Supply Connections
DC Voltage
Current
DC Connector
Type
Plug Size
Polarity

AD1847 Codec Connectors

When the AD1847 codec is enabled on the EZ-KIT Lite board, you can
access the audio input and output jacks on the board. Each of the audio
connectors are stereo mini jacks and accept standard commercially avail-
able stereo mini plugs.
ADSP-2181 EZ-KIT Lite Evaluation System Manual
, supplies DC voltages to the EZ-KIT Lite board.
J4
Table
Connection
8–10v dc @ 300mA
positive
8 to 10V DC
300 mA
Switchcraft 760 style FEMALE
5.5 (OD) X 2.1 (ID) X 12 (length) millimeters
Center is Negative (inside terminal)
EZ-KIT Hardware Reference
3-2.
