Expansion Port Connectors

Two expansion port connectors (
ADSP-2181 processor's bus signals, letting you watch data transmissions.
The and
P2 P3
tion, the host interface, interrupt, and
this connector
Figure 3-4. Expansion Connector
#
External port loading can effect external bus speed and
performance.
Table 3-1 describes the signals available on the
Table 3-1. Expansion Connectors
P2
Pin Signal
Number Name
1 A0
3 A2
5 A4
7 A6
9 A8
11 A10
13 A12
15 D0
ADSP-2181 EZ-KIT Lite Evaluation System Manual
connectors are sites for 50-pin header connectors. In addi-
Pin Signal
Number Name
2 A1
4 A3
6 A5
8 A7
10 A9
12 A11
14 A13
16 D1
EZ-KIT Hardware Reference
and ) provide access to the
P2 P3
pins are also available on
PWM_EVENT
and
P2
P3
Pin Signal
Number Name
1 GND
3 IAD1
5 IAD3
7 IAD5
9 IAD7
11 IAD9
13 IAD11
15 IAD13
pins.
P3
Pin Signal
Number Name
2 IAD0
4 IAD2
6 IAD4
8 IAD6
10 IAD8
12 IAD10
14 IAD12
16 IAD14
3-7
