ADZS-BF707-BLIP2 Board Hardware Reference

Power Connector (P5)

Part Description
0.65 mm power jack
5.0VDC@3.6A power supply

RF Wireless Connector (J2)

Part Description
4 x 2 0.05" pitch socket
4 x 2 0.05" pitch header

SD Connector (J3)

Part Description
SD 8-bit, 2 GB
2 GB
ADZS-BF707-BLIP2 Board Evaluation System Manual
Manufacturer
CUI
Mating Cable
GLOBETEK
Manufacturer Part Number
SAMTEC SFMC-104-T1-L-D
Mating Connector
SAMTEC FTSH-104-04-F-D
Manufacturer Part Number
SANDISK MHC-W21-601
Mating Connector
SANDISK SDSDB-2048-A11
Part Number
045-0883R
GS-1750(R)
2-11
