Calibrated 2 Mhz Rc Oscillator Frequency Vs. Temperature; Calibrated 2 Mhz Rc Oscillator Frequency Vs. V - Atmel ATmega128 Manual

2467S–AVR–07/09
Figure 196. Calibrated 2 MHz RC Oscillator Frequency vs. Temperature
CALIBRATED 2MHz RC OSCILLATOR FREQUENCY vs. TEMPERATURE
2.05
2
1.95
1.9
1.85
1.8
1.75
-60 -40
Figure 197. Calibrated 2 MHz RC Oscillator Frequency vs. V
CALIBRATED 2MHz RC OSCILLATOR FREQUENCY vs. Vcc
2.05
2
1.95
1.9
1.85
1.8
2.5 3
-20 0 20
Temperature
3.5 4
V (V)
CC
ATmega128
40 60 80
CC
4.5 5
5.5 V
5.0 V
4.5 V
4.0 V
3.6 V
3.3 V
2.7 V
100
-40 ˚C
25 ˚C
85 ˚C
5.5
351
