Table 52. Waveform Generation Mode Bit Description
(1)
WGM01 WGM00
Mode (CTC0) (PWM0)
0 0
1 0
2 1
3 1
Note: 1. The CTC0 and PWM0 bit definition names are now obsolete. Use the WGM01:0 definitions.
However, the functionality and location of these bits are compatible with previous versions of
the timer.
• Bit 5:4 – COM01:0: Compare Match Output Mode
These bits control the output compare pin (OC0) behavior. If one or both of the COM01:0 bits
are set, the OC0 output overrides the normal port functionality of the I/O pin it is connected to.
However, note that the Data Direction Register (DDR) bit corresponding to OC0 pin must be set
in order to enable the output driver.
When OC0 is connected to the pin, the function of the COM01:0 bits depends on the WGM01:0
bit setting. Table 53 shows the COM01:0 bit functionality when the WGM01:0 bits are set to a
normal or CTC mode (non-PWM).
Table 53. Compare Output Mode, non-PWM Mode
COM01 COM00
0 0
0 1
1 0
1 1
Table 54 shows the COM01:0 bit functionality when the WGM01:0 bits are set to fast PWM
mode.
Table 54. Compare Output Mode, Fast PWM Mode
COM01 COM00
0 0
0 1
1 0
1 1
Note: 1. A special case occurs when OCR0 equals TOP and COM01 is set. In this case, the compare
match is ignored, but the set or clear is done at BOTTOM. See
for more details.
Table 55 shows the COM01:0 bit functionality when the WGM01:0 bits are set to phase correct
PWM mode.
(1)
Timer/Counter
Mode of Operation
0 Normal
1 PWM, Phase
Correct
0 CTC
1 Fast PWM
Description
Normal port operation, OC0 disconnected.
Toggle OC0 on compare match
Clear OC0 on compare match
Set OC0 on compare match
Description
Normal port operation, OC0 disconnected.
Reserved
Clear OC0 on compare match, set OC0 at BOTTOM,
(non-inverting mode)
Set OC0 on compare match, clear OC0 at BOTTOM,
(inverting mode)
ATmega128
Update of TOV0 Flag
TOP OCR0 at Set on
0xFF Immediate MAX
0xFF TOP BOTTOM
OCR0 Immediate MAX
0xFF BOTTOM MAX
(1)
"Fast PWM Mode" on page 99
