Atmel ATmega2564RFR2 Manual

Features
• Network support by hardware assisted Multiple PAN Address Filtering
• Advanced Hardware assisted Reduced Power Consumption
• High Performance, Low Power AVR
• Advanced RISC Architecture
- 135 Powerful Instructions – Most Single Clock Cycle Execution
- 32x8 General Purpose Working Registers / On-Chip 2-cycle Multiplier
- Up to 16 MIPS Throughput at 16 MHz and 1.8V – Fully Static Operation
• Non-volatile Program and Data Memories
- 256K/128K/64K Bytes of In-System Self-Programmable Flash
• Endurance: 10'000 Write/Erase Cycles @ 125° C (25'000 Cycles @ 85° C)
- 8K/4K/2K Bytes EEPROM
• Endurance: 20'000 Write/Erase Cycles @ 125° C (100'000 Cycles @ 25° C)
- 32K/16K/8K Bytes Internal SRAM
• JTAG (IEEE std. 1149.1 compliant) Interface
- Boundary-scan Capabilities According to the JTAG Standard
- Extensive On-chip Debug Support
- Programming of Flash EEPROM, Fuses and Lock Bits through the JTAG interface
• Peripheral Features
- Multiple Timer/Counter & PWM channels
- Real Time Counter with Separate Oscillator
- 10-bit, 330 ks/s A/D Converter; Analog Comparator; On-chip Temperature Sensor
- Master/Slave SPI Serial Interface
- Two Programmable Serial USART
- Byte Oriented 2-wire Serial Interface
• Advanced Interrupt Handler and Power Save Modes
• Watchdog Timer with Separate On-Chip Oscillator
• Power-on Reset and Low Current Brown-Out Detector
• Fully integrated Low Power Transceiver for 2.4 GHz ISM Band
- High Power Amplifier support by TX spectrum side lobe suppression
- Supported Data Rates: 250 kb/s and 500 kb/s, 1 Mb/s, 2 Mb/s
- -100 dBm RX Sensitivity; TX Output Power up to 3.5 dBm
- Hardware Assisted MAC (Auto-Acknowledge, Auto-Retry)
- 32 Bit IEEE 802.15.4 Symbol Counter
- SFD-Detection, Spreading; De-Spreading; Framing ; CRC-16 Computation
- Antenna Diversity and TX/RX control / TX/RX 128 Byte Frame Buffer
• PLL synthesizer with 5 MHz and 500 kHz channel spacing for 2.4 GHz ISM Band
• Hardware Security (AES, True Random Generator)
• Integrated Crystal Oscillators (32.768 kHz & 16 MHz, external crystal needed)
• I/O and Package
- 33 Programmable I/O Lines
- 48-pad QFN (RoHS/Fully Green)
• Temperature Range: -40° C to 125° C Industrial
• Ultra Low Power consumption (1.8 to 3.6V) for AVR & Rx/Tx: 10.1mA/18.6 mA
- CPU Active Mode (16MHz): 4.1 mA
- 2.4GHz Transceiver: RX_ON 6.0 mA / TX 14.5 mA (maximum TX output power)
- Deep Sleep Mode: <700nA @ 25° C
• Speed Grade: 0 – 16 MHz @ 1.8 – 3.6V range with integrated voltage regulators
Applications
®
• ZigBee / IEEE 802.15.4-2011/2006/2003
• General Purpose 2.4GHz ISM Band Transceiver with Microcontroller
• RF4CE, SP100, WirelessHART
42073BS-MCU Wireless-09/14
®
8-Bit Microcontroller
™
– Full and Reduced Function Device
™
, ISM Applications and IPv6 / 6LoWPAN
ATmega2564/1284/644RFR2
8-bit
Microcontroller
with Low Power
2.4GHz
Transceiver for
ZigBee and
IEEE 802.15.4
ATmega2564RFR2
ATmega1284RFR2
ATmega644RFR2
42073BS-MCU Wireless-09/14
