Atmel ATmega128 Manual page 270

ATmega128
270
Table 106. ATmega128 Boundary-scan Order (Continued)
Bit Number Signal Name
67 PG0.Control
66 PG0.Pullup_Enable
65 PG1.Data
64 PG1.Control
63 PG1.Pullup_Enable
62 PC0.Data
61 PC0.Control
60 PC0.Pullup_Enable
59 PC1.Data
58 PC1.Control
57 PC1.Pullup_Enable
56 PC2.Data
55 PC2.Control
54 PC2.Pullup_Enable
53 PC3.Data
52 PC3.Control
51 PC3.Pullup_Enable
50 PC4.Data
49 PC4.Control
48 PC4.Pullup_Enable
47 PC5.Data
46 PC5.Control
45 PC5.Pullup_Enable
44 PC6.Data
43 PC6.Control
42 PC6.Pullup_Enable
41 PC7.Data
40 PC7.Control
39 PC7.Pullup_Enable
38 PG2.Data
37 PG2.Control
36 PG2.Pullup_Enable
35 PA7.Data
34 PA7.Control
33 PA7.Pullup_Enable
32 PA6.Data
Module
Port G
Port C
Port G
Port A
2467S–AVR–07/09
