Target CPU reset signal. Typically connected to the RESET pin

of the target CPU, which is typically called "nRST", "nRESET"

or "RESET". This signal is an active low signal.

Leave open on target side

This pin can be used to supply power to the target hardware.

Older J-Links may not be able to supply power on this pin. For

more information about how to enable/disable the power sup-

ply, please refer to Target power supply .
