Parameter
WorkRAMSize
Core
JLinkScriptFile
Notes
• No separate closing tag.
Directly closed after attributes have been specified: <ChipInfo ... />
• Must not occur outside a <Device> tag.
10.5.3.1 Attribute values - Core
The following values are valid for the
•
JLINK_CORE_CORTEX_M1
•
JLINK_CORE_CORTEX_M3
•
JLINK_CORE_CORTEX_M3_R1P0
•
JLINK_CORE_CORTEX_M3_R1P1
•
JLINK_CORE_CORTEX_M3_R2P0
•
JLINK_CORE_CORTEX_M3_R2P1
•
JLINK_CORE_CORTEX_M0
•
JLINK_CORE_CORTEX_M_V8BASEL
•
JLINK_CORE_ARM7
•
JLINK_CORE_ARM7TDMI
•
JLINK_CORE_ARM7TDMI_R3
•
JLINK_CORE_ARM7TDMI_R4
•
JLINK_CORE_ARM7TDMI_S
•
JLINK_CORE_ARM7TDMI_S_R3
•
JLINK_CORE_ARM7TDMI_S_R4
•
JLINK_CORE_CORTEX_A8
•
JLINK_CORE_CORTEX_A7
•
JLINK_CORE_CORTEX_A9
•
JLINK_CORE_CORTEX_A12
•
JLINK_CORE_CORTEX_A15
•
JLINK_CORE_CORTEX_A17
•
JLINK_CORE_ARM9
•
JLINK_CORE_ARM9TDMI_S
•
JLINK_CORE_ARM920T
•
JLINK_CORE_ARM922T
•
JLINK_CORE_ARM926EJ_S
•
JLINK_CORE_ARM946E_S
•
JLINK_CORE_ARM966E_S
•
JLINK_CORE_ARM968E_S
•
JLINK_CORE_ARM11
•
JLINK_CORE_ARM1136
•
JLINK_CORE_ARM1136J
•
JLINK_CORE_ARM1136J_S
J-Link / J-Trace (UM08001)
CHAPTER 10
Hexadecimal value that specifies the size of the RAM area
that can be used by J-Link during flash programming etc.
Cannot exist without also specifying WorkRAMAddr. If no
flash banks are added for the new device, this attribute is
optional.
E.g. WorkRAMSize="0x10000"
Specifies the core that the device incorporates. If a new de-
vice added, this attribute is mandatory.
E.g. Core="JLINK_CORE_CORTEX_M0"
For a list of valid attribute values, please refer to Attribute
values - Core .
String that specifies the path to a J-Link script file if required
for the device. Path can be relative or absolute. If path is
relative, is relative to the location of the JLinkDevices.xml
file. This attribute is mandatory.
E.g. JLinkScriptFile="ST/Example.jlinkscript"
Core attribute:
© 2004-2017 SEGGER Microcontroller GmbH & Co. KG
XML Tags and Attributes
Meaning
