IPv4 Access Control Lists (ACLs)
Editing an Existing ACL
ProCurve(config)# ip access-list standard Accounting
ProCurve(config-std-nacl)# permit host 10.10.10.115
ProCurve(config-std-nacl)# deny 10.10.10.1/24
ProCurve(config-std-nacl)# remark Marketing
ProCurve(config-std-nacl)# remark Channel_Mktg
ProCurve(config-std-nacl)# show run
.
.
.
ip access-list standard "Accounting"
10 permit 10.10.10.115 0.0.0.0
20 deny 10.10.10.1 0.0.0.255
30 remark "Channel_Mktg"
exit
Figure 9-25. Example of Overwriting One Remark with Another
9-84

Operating Notes for Remarks

The resequence command ignores "orphan" remarks that do not have
■
an ACE counterpart with the same sequence number. For example, if:
• a remark numbered "55" exists in an ACE
• there is no ACE numbered "55" in the same ACL
resequence is executed on an ACL
•
then the remark retains "55" as its sequence number and will be placed in
the renumbered version of the ACL according to that sequence number.
■ Entering an unnumbered remark followed by a numbered ACE, or the
reverse, creates an "orphan" remark. The unnumbered entry will be
assigned a sequence number that is an increment from the last ACE
in the list. The numbered entry will then be placed sequentially in the
list according to the sequence number used.
■ Configuring two remarks without either sequence numbers or an
intervening, unnumbered ACE results in the second remark over­
writing the first.
Where multiple remarks are
sequentially entered for
automatic inclusion at the end of
an ACL, each successive remark
replaces the previous one until an
ACE is configured for automatic
inclusion at the end of the list.
