ACE Syntax Nas-filter-Rule ="< permit | deny > in <ip | ip-protocol-value > from any to
(Standard
< any | ip-addr | ipv4-addr/mask > [ < tcp/udp-port | tcp/udp-port range > | icmp-type ] [cnt ]"
Attribute-92)
ACE Syntax HP-Nas-filter-Rule="< permit | deny > in <ip | ip-protocol-value > from any to
(Legacy VSA-
< any | ip-addr | ipv4-addr/mask > [ < tcp/udp-port | tcp/udp-port range > | icmp-type ] [cnt ]"
61)
: Standard attribute for filtering inbound IPv4 traffic from an authenticated
Nas-filter-Rule =
client. Refer also to table 6-4, "Nas-Filter-Rule Attribute Options" on page 6-18.
HP-Nas-filter-Rule = :
client. Refer also to table 6-4, "Nas-Filter-Rule Attribute Options" on page 6-18.
" "
. . . : Must be used to enclose and identifies a complete permit or deny ACE syntax
statement. For example:
< permit | deny >: Specifies whether to forward or drop the identified IP traffic type from the
authenticated client. (For information on explicitly permitting or denying all inbound IP
traffic from an authenticated client, or for implicitly denying all such IP traffic not already
permitted or denied, refer to "Configuration Notes" on page 6-24.)
in: Required keyword specifying that the ACL applies only to the traffic inbound from the
authenticated client.
< ip | ip-protocol-value >: Options for specifying the type of traffic to filter.
ip: Applies the ACE to all IP traffic from the authenticated client.
ip-protocol-value:
a protocol number or by
numbers is 0-255. (Protocol numbers are defined in RFC 2780. For a complete listing,
refer to "Protocol Registries" on the Web site of the Internet Assigned Numbers
Authority at www.iana.com.) Some examples of protocol numbers include:
1 = ICMP
2 = IGMP (IPv4 only)
6 = TCP*IPv4 traffic only.
from any: Required keywords specifying the (authenticated) client source. (Note that a
RADIUS-assigned ACL assigned to a port filters only the inbound traffic having a source
MAC address that matches the MAC address of the client whose authentication invoked the
ACL assignment.)
to: Required destination keyword.

Configuring ACE Syntax in RADIUS Servers

The following syntax and operating information applies to ACLs configured
in a RADIUS server.
Legacy HP VSA for filtering inbound IPv4 traffic from an authenticated
Nas-filter-Rule="deny in tcp from any to 0.0.0.0/0 23"
This option applies the ACE to the type of IP traffic specified by either
,
tcp udp
17 = UDP
Configuring RADIUS Server Support for Switch Services
Configuring and Using RADIUS-Assigned Access Control Lists
,
icmp , or (for IPv4-only) igmp. The range of protocol
6-19
