HP J9146A - ProCurve Switch 2910al-24G-PoE Installation And Getting Started Manual

Installation guide.
Hide thumbs
ProCurve 2910al Switches
Installation and Getting Started Guide
Power over Ethernet

Advertising

   Related Manuals for HP J9146A - ProCurve Switch 2910al-24G-PoE

   Summary of Contents for HP J9146A - ProCurve Switch 2910al-24G-PoE

  • Page 1

    ProCurve 2910al Switches Installation and Getting Started Guide Power over Ethernet...

  • Page 3

    ProCurve 2910al Switches Installation and Getting Started Guide...

  • Page 4

    HP shall not be liable for technical or editorial errors or omissions contained herein. HP ProCurve 2910al-24G Switch (J9145A) Hewlett-Packard assumes no responsibility for the use or HP ProCurve 2910al-48G Switch (J9147A) reliability of its software on equipment that is not furnished...

  • Page 5: Table Of Contents

    Contents 1 Introducing the Switch Front of the Switch ..........1-4 Network Ports .

  • Page 6: Table Of Contents

    4. Mount the Switch ........2-11 Rack or Cabinet Mounting .

  • Page 7: Table Of Contents

    4 Troubleshooting Basic Troubleshooting Tips ........4-1 Diagnosing with the LEDs .

  • Page 8: Table Of Contents

    Installing the Patch Cord ........C-5 Twisted-Pair Cable/Connector Pin-Outs .

  • Page 9: Introducing The Switch

    Introducing the Switch The HP ProCurve 2910al Switches are multiport switches that can be used to build high-performance switched networks. These switches are store-and- forward devices offering low latency for high-speed networking. The 2910al switches also support Redundant Power Supply and Power over Ethernet technologies.

  • Page 10

    Introducing the Switch The 2910al-24G Switch and 2910al-48G Switch have respectively, 24 or 48, auto-sensing 10/100/1000Base-T RJ-45 ports, four dual-personality ports— either auto-sensing 10/100/1000Base-T RJ-45 or mini-GBIC, and two slots are provided in the back of the device to support expansion modules: 2-port (two fixed CX4 ports) 10 Gigabit per second Ethernet (10-GbE) ■...

  • Page 11

    Introducing the Switch The 2910al-PoE+ Switches also support Power over Ethernet+ (PoE+) technology. PoE+ offers a higher wattage per port than the previous PoE offering, 30 watts per port instead of 15. The switches support 802.3af standard devices and some pre-standard PoE devices. It also supports the draft version of the 802.3at standard.

  • Page 12: Front Of The Switch

    Introducing the Switch Front of the Switch Front of the Switch Temp, Fan, and Test Power, Status LEDs Fault, and Locator Switch port LEDs LEDs Auxiliary port Module, and RPS, and LED* Status LEDs Port LED Mode select 10/100/1000Base-T RJ-45 button and indicator LEDs Console port Dual-personality ports...

  • Page 13

    Introducing the Switch Front of the Switch PoE, Temp, Fan, and Power, Test Status LEDs Fault, and locator LEDs Switch port LEDs Module, EPS, and Auxiliary port RPS Status LEDs and LED* Port LED Mode select button and indicator LEDs Console port 10/100/1000Base-T RJ-45 Dual-personality ports...

  • Page 14: Network Ports, Leds

    Introducing the Switch Front of the Switch Network Ports ■ 24 or 48 auto-sensing 10/100/1000Base-T ports. All these ports have the “Auto MDIX” feature, which means you can use either straight-through or crossover twisted-pair cables to connect any network devices to the switch. ■...

  • Page 15

    Introducing the Switch Front of the Switch Switch LEDs State Meaning Locator (Blue) The Locator LED is used to locate a specific chassis in a area full of chassis. The Flashing LED can be set to be on solid or flash for a specified number of minutes (1-1440). The default is 30 minutes.

  • Page 16: Led Mode Select Button And Indicator Leds

    Introducing the Switch Front of the Switch Switch LEDs State Meaning RPS Status Normal operation. RPS is connected and operating correctly. RPS could be powering the unit. (green) Flashing RPS is connected but has experienced a fault. RPS is not connected or is not powered on. EPS Status Connected to an External Power Supply, and receiving power.

  • Page 17

    Introducing the Switch Front of the Switch Port LEDs Link Expansion Module LED and Mode LED Mode select button and indicator LEDs Figure 1-5. HP ProCurve 2910al-48G Switch Expansion Module LEDs Port LEDs Link and Mode LED Mode select button and indicator LEDs Figure 1-6.

  • Page 18: Reset Button, Clear Button

    Introducing the Switch Front of the Switch The Usr Mode LED is reserved for future development ■ ■ If the PoE indicator LED is lit, the Link and Mode LEDs indicate PoE status: Link LED: • On = PoE is enabled on this port •...

  • Page 19: Console Port, Expansion Module Leds

    Introducing the Switch Front of the Switch Console Port This port is used to connect a console to the switch by using the RJ-45 to DB9 cable, supplied with the switch. This connection is described under “Connect a Console to the Switch” in chapter 2, “Installing the Switch.” The console can be a PC or workstation running a VT-100 terminal emulator, or a VT-100 terminal.

  • Page 20: Back Of The Switch, Al Module Slots

    Introducing the Switch Back of the Switch Back of the Switch RPS Input Port AC power connector al module slots Auxiliary Port and LED Figure 1-7. HP ProCurve 2910al-48G Switch EPS Input Port al module slot AC power connector RPS Input Port Figure 1-8.

  • Page 21: Rps And Eps Input Ports, Power Connector

    Introducing the Switch Back of the Switch RPS and EPS Input Ports The 2910al Switches support connectivity to a redundant power supply (RPS/ EPS). The HP ProCurve 620 Redundant and External Power Supply (J8696A) and the HP ProCurve 630 Redundant and/or External Power Supply (J9443A) are accessory products for these switches.

  • Page 22: Hp Procurve Switch Al Modules

    Introducing the Switch HP ProCurve Switch al Modules HP ProCurve Switch al Modules The HP ProCurve al Modules are components you can add to a HP ProCurve al switch to provide a variety of network connectivity options. The following modules is available as of this printing: Module Description HP ProCurve 10-GbE...

  • Page 23: Features

    Introducing the Switch Features Features HP ProCurve 10-GbE CX4 al Module Module Status LEDs Retaining screw Link and Mode LEDs Copper CX4 port connections (one pair per port) Figure 2. Front of the al 10-GbE CX4 Module The al Modules have the following features: ■...

  • Page 24: Switch Features

    Introducing the Switch Switch Features Switch Features The features of the 2910al Switch include: ■ 24 or 48 auto-sensing 10/100/1000Base-T RJ-45 ports with Auto-MDIX. ■ Four dual-personality ports—either the auto sensing 10/100/1000Base-T RJ-45 or the mini-GBIC can be used for each port. ■...

  • Page 25

    Introducing the Switch Switch Features • ProCurve Manager—an SNMP-based, graphical network manage- ment tool that you can use to manage your entire network. This product is included with your new switch. Support for the Spanning Tree Protocol to eliminate network loops ■...

  • Page 27: Included Parts

    Installing the Switch The HP ProCurve 2910al Switches come with an accessory kit that includes the brackets for mounting the switch in a standard 19-inch telco rack, in an equipment cabinet, and with rubber feet that can be attached so the switch can be securely located on a horizontal surface.

  • Page 28

    Installing the Switch Included Parts ■ Accessory kit (5069-5705) two mounting brackets eight 8-mm M4 screws to attach the mounting brackets to the switch four 5/8-inch number 12-24 screws to attach the switch to a rack four rubber feet ■ Power cord, one of the following: Non-PoE Switches PoE+ Switches...

  • Page 29: Installation Precautions:

    Installing the Switch Included Parts Installation Precautions: Follow these precautions when installing the 2910al Switches. W A R N I N G ■ The rack or cabinet should be adequately secured to prevent it from becoming unstable and/or falling over. Devices installed in a rack or cabinet should be mounted as low as ■...

  • Page 30: Installation Procedures, Summary

    Installing the Switch Installation Procedures Figure 2-1. Air flow direction of the 2910al switch Installation Procedures Summary Prepare the installation site (page 2-5). Ensure the physical environ- ment is properly prepared, including having the correct network cabling ready to connect to the switch and having an appropriate location for the switch.

  • Page 31: Prepare The Installation Site, Verify The Switch Passes Self Test

    Installing the Switch Installation Procedures (Optional) Connect an external power supply (page 2-18). You may wish to use an HP ProCurve external power supply, either the 620 RPS/ EPS or the 630 RPS/EPS with your 2910-PoE+ switch. To do so you must connect the external power supply using the RPS or EPS cables supplied with these devices.

  • Page 32

    Installing the Switch Installation Procedures Connect the power cord supplied with the switch to the power connector on the back of the switch, and then into a properly grounded electrical outlet. Figure 2-2. Connecting the power cord N o t e These switches do not have a power switch.

  • Page 33: Led Behavior:

    Installing the Switch Installation Procedures Switch port LEDs Power and Fault LEDs Test LED Figure 2-4. Checking the LEDs on the 2910al-PoE+ switches LED Behavior: During the self test: • Initially, all the status, LED Mode and port LEDs are on for most of the duration of the test.

  • Page 34: Optional) Install A Module

    Installing the Switch Installation Procedures 3. (Optional) Install a Module N o t e The expansion al module is “hot pluggable.” You can insert or remove a module while the switch is powered on without interrupting the operation of the rest of the switch ports.

  • Page 35: Installing The Interconnect Kit

    Installing the Switch Installation Procedures Installing the Interconnect Kit The Interconnect Kit consists of two, 1-port 10 Gigabit switch expansion modules (J9165A) and one 0.5 meter cable used specifically for this interconnect kit. These modules have 1 fixed CX4 port each. The interconnect kit is used for 10-GbE (high speed) connectivity.

  • Page 36: Verifying The Module Is Installed Correctly

    Installing the Switch Installation Procedures Verifying the Module is Installed Correctly Observe the Module Status and Fault LEDs on the front of the switch to verify the module is installed properly. Module Status LED Figure 2-8. Location of Module Status LEDs When the module is installed properly and the switch is powered on, or the module is installed when the switch already has power, the module undergoes a self test that takes a few seconds.

  • Page 37: Mount The Switch, Rack Or Cabinet Mounting, Rack Mounting The Switch

    Installing the Switch Installation Procedures 4. Mount the Switch After the switch passes self test, it is ready to be mounted in a stable location. The 2910al Switches can be mounted in these ways: Mounting Location Non-PoE Switches PoE Switches In a rack or cabinet On a horizontal surface On a wall...

  • Page 38

    Installing the Switch Installation Procedures 8 mm M4 screws Figure 2-9. Attaching mounting brackets N o t e The mounting brackets have multiple mounting holes and can be rotated allowing for a wide variety of mounting options. These include mounting the switch so its front face is flush with the face of the rack, or mounting it in a more balanced position.

  • Page 39: Horizontal Surface Mounting

    Installing the Switch Installation Procedures Hold the switch with attached brackets up to the rack and move it vertically until rack holes line up with the bracket holes, then insert and tighten the four number 12-24 screws holding the brackets to the rack. Figure 2-10.

  • Page 40: Optional) Install A Transceiver, To Remove The Transceiver:

    Installing the Switch Installation Procedures 5. (Optional) Install a Transceiver N o t e Hot swapping transceivers is supported. You can install or remove a transceiver with the switch powered on, a reset will not occur. However, rapid hotswaps are not recommended. Wait 5 seconds between hotswaps. a.

  • Page 41: Installing Or Removing The Optical Media Converter

    Installing the Switch Installation Procedures Installing or Removing the Optical Media Converter You can connect an Optical Media Converter (OMC) to the fixed ports only. Use only HP ProCurve OMCs. Installing the OMC: Connect the OMC to the fixed port. Push it until it clicks.

  • Page 42: Optional) Install Mini-gbics And Sfps

    Installing the Switch Installation Procedures 6. (Optional) Install Mini-GBICs and SFPs You can install or remove a mini-GBIC from a mini-GBIC slot without having to power off the switch. Use only ProCurve mini-GBICs. When a mini-GBIC or SFP transceiver is inserted the switch authenticates it. This can take 1-3 seconds, with the worst case being 5 seconds.

  • Page 43: Removing The Mini-gbics

    Installing the Switch Installation Procedures N o t e Direct Attach Cables (DACs) are low- cost 10-GbE connectivity options consisting of a one, three, or seven meter cable with SFP+ connectors permanently attached to each end. Figure 2-13. One meter DAC Installing the mini-GBICs Hold the mini-GBIC by its sides and gently insert it into one of the slots on the switch until the mini-GBIC clicks into place.

  • Page 44: Connect The Switch To A Power Source, Optional) Connect An External Power Supply, Rps Operation

    Installing the Switch Installation Procedures To remove the mini-GBICs that have the plastic tab or plastic collar, push the tab or collar toward the switch until you see the mini-GBIC release from the switch (you can see it move outward slightly), and then pull it from the slot. To remove the mini-GBICs that have the wire bail, lower the bail until it is approximately horizontal, and then using the bail, pull the mini-GBIC from the slot.

  • Page 45: Operating Characteristics Of The 620 Rps/eps (j8696a)

    Installing the Switch Installation Procedures These external power supplies support hot plugging of the RPS cable without causing a reboot of the switch or causing the power supply in either of the power supplies, or switch to shut down temporarily or permanently. For more information refer to the documentation for the external power supplies located on the ProCurve Web site at www.hp.com/go/procurve/manuals.

  • Page 46

    Installing the Switch Installation Procedures Table 2-1. 620 RPS/EPS LEDs State Meaning Power The unit is powered on. (green) The unit is NOT powered on. Fault The normal state; indicates that there are no fault conditions on the unit. (orange) Flash A fault has occurred on the unit, one of the ports, or the fan.

  • Page 47: Rps/eps Connectivity

    Installing the Switch Installation Procedures 620 RPS/EPS Connectivity This section shows some recommended connection topologies using the 620 RPS/EPS. The 620 RPS/EPS can provide backup power support for up to two ProCurve switches. In the illustration below, two ProCurve Switch 2910s are connected to the RPS ports on a 620 RPS/EPS.

  • Page 48

    Installing the Switch Installation Procedures Operating characteristics of the HP ProCurve 630 RPS/EPS (J9443A) The HP ProCurve 630 RPS/EPS has one RPS port, which can provide redundant +12V power to a connected switch. If a switch with no AC power is connected to an operating HP ProCurve 630 RPS/EPS, the switch will not power on.

  • Page 49

    Installing the Switch Installation Procedures Table 2-2. HP ProCurve 630 RPS/EPS LEDs State Meaning Power The unit is powered on. (green) The unit is NOT powered on. Fault The normal state; indicates that there are no fault conditions on the unit. (orange) Flash A fault has occurred on the unit, one of the ports, or the fan.

  • Page 50: Hp Procurve 630 Rps/eps Connectivity, Optional) Connect A Console To The Switch

    Installing the Switch Installation Procedures HP ProCurve 630 RPS/EPS Connectivity This section shows the recommended connection topology using the HP ProCurve 630 RPS/EPS. The HP ProCurve 630 RPS/EPS can provide backup power support for only one ProCurve switch. In the illustration below, the ProCurve Switch 2910 is connected to the RPS and EPS ports on a HP ProCurve 630 RPS/EPS.

  • Page 51: Terminal Configuration, Direct Console Access

    Installing the Switch Installation Procedures Terminal Configuration To connect a console to the switch, configure the PC terminal emulator as a DEC VT-100 (ANSI) terminal or use a VT-100 terminal, and configure either one to operate with these settings: ■ any baud rate from 1200 to 115200 (the switch senses the speed) 8 data bits, 1 stop bit, no parity, and flow control set to Xon/Xoff ■...

  • Page 52: Console Cable Pinouts

    Installing the Switch Installation Procedures If you want to continue with console management of the switch at this time, see chapter 3, “Getting Started With Switch Configuration” for some basic configuration steps. For more detailed information, refer to the Management www.hp.com/ and Configuration Guide, which is on the ProCurve Website at go/procurve/manuals.

  • Page 53: Connect The Network Cables, Using The Rj-45 Connectors, Connecting Cables To Mini-gbics

    Installing the Switch Installation Procedures 10. Connect the Network Cables Connect the network cables, described under “Cabling Infrastructure” (page 2-5), from the network devices or your patch panels to the fixed RJ-45 ports on the switch or to any mini-GBICs you have installed in the switch. Using the RJ-45 Connectors To connect: Push the RJ-45 plug into the RJ-45 jack...

  • Page 54: Connecting A Fiber Cable, Connecting A Copper Cable

    Installing the Switch Installation Procedures Connecting a fiber cable To connect: 1. Remove the dust covers from the cable connectors and the port. 2. Aligning the notches on the cable connectors with the slots of the port, press the cable connector into the port until it snaps into place.

  • Page 55: Sample Network Topologies

    Installing the Switch Sample Network Topologies Sample Network Topologies This section shows a few sample network topologies in which the switch is implemented. For more topology information, see the ProCurve network products Website, www.hp.com/go/procurve. Servers ProCurve Switch 5406zl Gigabit fiber cable ProCurve Switch 2910al Gigabit copper cable PCs and peripherals...

  • Page 56

    Installing the Switch Sample Network Topologies Servers 10 Gigabit copper cables ProCurve Switch 5406zl 10 Gigabit fiber cable ProCurve Switch 2910al Gigabit copper cable Gigabit copper cable PCs and peripherals Figure 2-22. Example, high performance edge deployment 2-30...

  • Page 57

    Installing the Switch Sample Network Topologies High speed internet uplinks 10 Gigabit copper cables ProCurve Switch 5412zl 10 Gigabit copper cables 10 Gigabit fiber cable ProCurve Switch 2910al Gigabit copper Gigabit copper cable cable Servers with Gigabit Servers with Gigabit Ethernet NIC Ethernet NIC Figure 2-23.

  • Page 58

    Installing the Switch Sample Network Topologies Servers ProCurve Switch 5406zl 10 Gigabit fiber cable 10 Gigabit copper cables ProCurve Switch 2910al Gigabit copper cable PCs, peripherals and access points Figure 2-24. Example, PoE edge deployment 2-32...

  • Page 59: Getting Started With Switch Configuration, Recommended Minimal Configuration

    Getting Started With Switch Configuration This chapter is a guide for using the console Switch Setup screen to quickly assign an IP (Internet Protocol) address and subnet mask to the switch, set a Manager password, and, optionally, configure other basic features. For more information on using the switch console and the other switch management interfaces: the web browser interface and the SNMP manage- ment tool, ProCurve Manager, please see the Management and Configuration...

  • Page 60: Using The Console Setup Screen

    Getting Started With Switch Configuration Using the Console Setup Screen N o t e By default, the switch is configured to acquire an IP address configuration from a DHCP or Bootp server. To use DHCP/Bootp instead of the manual method described in this chapter, see “DHCP/Bootp Operation” in the Management and Configuration Guide, which is on the ProCurve Website at www.hp.com/go/procurve/manuals.

  • Page 61

    Getting Started With Switch Configuration Using the Console Setup Screen to the IP Config (DHCP/Bootp) field and use the Space bar to select the [Tab] Manual option. to the IP Address field and enter the IP address that is compatible with [Tab] your network.

  • Page 62: To Recover From A Lost Manager Password

    Getting Started With Switch Configuration Where to Go From Here Where to Go From Here The above procedure configures your switch with a Manager password, IP address, and subnet mask. As a result, with the proper network connections, you can now manage the switch from a PC equipped with Telnet, a web browser interface, or from an SNMP-based network management station using a tool such as ProCurve Manager.

  • Page 63: Starting A Telnet Session, Starting A Web Browser Session

    Getting Started With Switch Configuration Using the IP Address for Remote Switch Management Using the IP Address for Remote Switch Management With your switch, you can use the switch’s IP address to manage the switch from any PC that is on the same subnet as the switch. You can use either a Telnet session or a standard web browser to manage the switch.

  • Page 64

    Getting Started With Switch Configuration Using the IP Address for Remote Switch Management The operating systems, web browsers, and Java support required to manage the switch through the browser interface are listed in the following table: Operating System Internet Explorer Java Version Windows 2000 SP4 5.5 SP2, 6.0 SP1...

  • Page 65: Basic Troubleshooting Tips

    Troubleshooting This chapter describes how to troubleshoot your switch. This document describes troubleshooting mostly from a hardware perspective. You can perform more in-depth troubleshooting on the switch using the software tools available with the switch, including the full-featured console interface, the built-in web browser interface, and ProCurve Manager, the SNMP-based network management tool.

  • Page 66

    Troubleshooting Basic Troubleshooting Tips Because the switch behaves in this way (in compliance with the IEEE 802.3 standard), if a device connected to the switch has a fixed configu- ration at full duplex, the device will not connect correctly to the switch. The result will be high error rates and very inefficient communications between the switch and the device.

  • Page 67

    Troubleshooting Basic Troubleshooting Tips ■ Check the port configuration. A port on your switch may not be operating as you expect because it has been put into a “blocking” state by Spanning Tree, GVRP (automatic VLANs), or LACP (automatic trunking). (Note that the normal operation of the Spanning Tree, GVRP, and LACP features may put the port in a blocking state.) Or, the port just may have been configured as disabled through software.

  • Page 68: Diagnosing With The Leds

    Troubleshooting Diagnosing with the LEDs Diagnosing with the LEDs Table 4-1 shows LED patterns on the switch and the switch modules that indicate problem conditions. Check in the table for the LED pattern you see on your switch. Refer to the corresponding diagnostic tip on the next few pages. Table 4-1.

  • Page 69: Diagnostic Tips

    Troubleshooting Diagnosing with the LEDs Diagnostic Tips: Problem Solution ➊ The switch is not 1. Verify the power cord is plugged into an active power source and to the switch. Make plugged into an sure these connections are snug. active AC power 2.

  • Page 70

    Troubleshooting Diagnosing with the LEDs Problem Solution ➏ The network Try the following procedures: connection is not • For the indicated port, verify both ends of the cabling, at the switch and the connected working device, are connected properly. properly. •...

  • Page 71

    Troubleshooting Diagnosing with the LEDs Problem Solution ➐ The port may be Use the switch console to see if the port is part of a dynamic trunk (through the LACP improperly feature) or to see if Spanning Tree is enabled on the switch, and to see if the port may configured, or have been put into a “blocking”...

  • Page 72: Proactive Networking

    Troubleshooting Proactive Networking Proactive Networking The ProCurve 2910al Switches have built-in management capabilities that proactively help you manage your network including: ■ finding and helping you fix the most common network error conditions (for example, faulty network cabling, and non-standard network topolo- gies) informing you of the problem with clear, easy-to-understand messages ■...

  • Page 73: Hardware Diagnostic Tests, Testing The Switch By Resetting It, Checking The Switch Leds

    Troubleshooting Hardware Diagnostic Tests Hardware Diagnostic Tests Testing the Switch by Resetting It If you believe the switch is not operating correctly, you can reset the switch to test its circuitry and operating code. To reset a switch, either: ■ unplug and plug in the power cord (power cycling) press the Reset button on the front of the switch ■...

  • Page 74: Testing Twisted-pair Cabling, Testing Switch-to-device Network Communications, Testing End-to-end Network Communications

    Troubleshooting Hardware Diagnostic Tests Testing Twisted-Pair Cabling Network cables that fail to provide a link or provide an unreliable link between the switch and the connected network device may not be compatible with the IEEE 802.3 Type 10Base-T, 100Base-TX, or 1000Base-T standards. The twisted- pair cables attached to the Switch must be compatible with the appropriate standards.

  • Page 75: Restoring The Factory Default Configuration

    Troubleshooting Restoring the Factory Default Configuration Restoring the Factory Default Configuration As part of your troubleshooting process on the switch, it may become neces- sary to return the switch configuration to the factory default settings. This process momentarily interrupts the switch operation, clears any passwords, clears the console event log, resets the network counters to zero, performs a complete self test, and reboots the switch into its factory default configuration including deleting the IP address, if one is configured.

  • Page 76: Downloading New Switch Software, Hp Customer Support Services, Before Calling Support

    HP Customer Support Services If you are still having trouble with your switch, Hewlett-Packard offers support 24 hours a day, seven days a week through the use of a number of automated electronic services. See the Customer Support/Warranty booklet that came with your switch for information on how to use these services to get technical support.

  • Page 77: Physical, Electrical, Environmental

    Switch Specifications Physical 2910al-24G (J9145A) 2910al-48G (J9147A) 2910al-24G-PoE+ (J9146A) 2910al-48G-PoE+ (J9148A) Width: 44.19 cm (17.4 in) 44.19 cm (17.4 in) 44.19 cm (17.4 in) 44.19 cm (17.4 in) Depth: 36.57 cm (14.4 in) 36.57 cm (14.4 in) 36.57 cm (14.4 in) 36.57 cm (14.4 in) Height: 4.4 cm (1.7 in)

  • Page 78: Acoustic, Safety

    Switch Specifications Acoustic ProCurve Switch 2910al-24G (J9145A) Geraeuschemission LpA=41.1 dB am fiktiven Arbeitsplatz nach DIN 45635 T.19 Noise Emission LpA=41.1 dB at virtual workspace according to DIN 45635 T.19 ProCurve Switch 2910al-48G (J9147A) Geraeuschemission LpA=41.1 dB am fiktiven Arbeitsplatz nach DIN 45635 T.19 Noise Emission LpA=41.1 dB at virtual workspace according to DIN 45635 T.19...

  • Page 79

    Switch Specifications Table A-1. Technology standards and safety compliance Laser safety information Technology Compatible with EN/IEC SFP ("mini-GBIC") Lasers SFP+ Media these IEEE standard Lasers Converter standards compliance Lasers 10/100/1000-T IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T 100-FX IEEE 802.3u EN/IEC Class 1 Laser Product...

  • Page 81: Optical Power Specifications

    Module Specifications Module Specifications Physical Modules Width: 106.17 mm (4.18 in) Depth: 104.39 mm (4.11 in) Height: 35.56 mm (1.40 in) Weight: 0.159 kg (.35 lbs) Environmental MODULE Operating Non-Operating Temperature: 0C to 55C (32F to 131F) -40C to 70C (-40F to 158F) Relative humidity: 15% to 95% at 40C (104F) 15% to 90% at 65C (149F)

  • Page 83: Cabling Specifications

    Cabling and Technology Information This appendix includes network cable information for cables that should be used with the Switch 2910al, including minimum pin-out information and specifications for twisted-pair cables. N o t e Incorrectly wired cabling is the most common cause of problems for LAN communications.

  • Page 84

    Cabling and Technology Information Note on 1000Base-T Cable Requirements. The Category 5 networking cables that work for 100Base-TX connections should also work for 1000Base-T, as long as all four-pairs are connected. But, for the most robust connections you should use cabling that complies with the Category 5e specifications, as described in Addendum 5 to the TIA-568-A standard (ANSI/ TIA/EIA-568-A-5).

  • Page 85: Technology Distance Specifications

    Cabling and Technology Information Technology distance specifications Table C-2. Technology Supported cable type Multimode fiber Supported distances modal bandwidth 100-FX multimode fiber up to 2,000 meters 100-BX single mode fiber 0.5 - 10,000 meters 1000-T twisted-pair copper up to 100 meters 1000-SX multimode fiber 160 MHz*km...

  • Page 86: Mode Conditioning Patch Cord

    Cabling and Technology Information Mode Conditioning Patch Cord The following information applies to installations in which multimode fiber- optic cables are connected to a Gigabit-LX port or a 10-Gigabit LRM port. Multimode cable has a design characteristic called “Differential Mode Delay”, which requires the transmission signals be “conditioned”...

  • Page 87: Installing The Patch Cord

    Cabling and Technology Information Installing the Patch Cord As shown in the illustration below, connect the patch cord to the ProCurve transceiver with the section of single mode fiber plugged in to the Tx (transmit) port. Then, connect the other end of the patch cord to your network cabling patch panel, or directly to the network multimode fiber.

  • Page 88: Twisted-pair Cable/connector Pin-outs

    Cabling and Technology Information Twisted-Pair Cable/Connector Pin-Outs Auto-MDIX Feature: The 10/100/1000-T ports support the IEEE 802.3ab standard, which includes the “Auto MDI/MDI-X” feature. In the default configuration, “Auto”, the ports on the Switch 2910al all automatically detect the type of port on the connected device and operate as either an MDI or MDI- X port, whichever is appropriate.

  • Page 89: Straight-through Twisted-pair Cable For 10 Mbps Or 100 Mbps Network Connections, Cable Diagram, Pin Assignments

    Cabling and Technology Information Straight-Through Twisted-Pair Cable for 10 Mbps or 100 Mbps Network Connections Because of the HP Auto-MDIX operation of the 10/100 ports on the switch, for all network connections, to PCs, servers or other end nodes, or to hubs or other switches, you can use straight-through cables.

  • Page 90: Crossover Twisted-pair Cable For 10 Mbps Or 100 Mbps Network Connection, Cable Diagram, Pin Assignments

    Cabling and Technology Information Crossover Twisted-Pair Cable for 10 Mbps or 100 Mbps Network Connection The HP Auto-MDIX operation of the 10/100 ports on the switch also allows you to use crossover cables for all network connections, to PCs, servers or other end nodes, or to hubs or other switches.

  • Page 91: Mbps Network Connections, Cable Diagram, Pin Assignments

    Cabling and Technology Information Straight-Through Twisted-Pair Cable for 1000 Mbps Network Connections 1000Base-T connections require that all four pairs or wires be connected. Cable Diagram N o t e Pins 1 and 2 on connector “A” must be wired as a twisted pair to pins 1 and 2 on connector “B”.

  • Page 93: Safety Information

    Safety and EMC Regulatory Statements Safety Information Documentation reference symbol. If the product is marked with this symbol, refer to the product documentation to get more information about the product. WARNING A WARNING in the manual denotes a hazard that can cause injury or death.

  • Page 94: Informations Concernant La Sécurité

    Safety and EMC Regulatory Statements Informations concernant la sécurité Informations concernant la sécurité Symbole de référence à la documentation. Si le produit est marqué de ce symbole, reportez-vous à la documentation du produit afin d'obtenir des informations plus détaillées. WARNING Dans la documentation, un WARNING indique un danger susceptible d'entraîner des dommages corporels ou la mort.

  • Page 95: Hinweise Zur Sicherheit

    Safety and EMC Regulatory Statements Hinweise zur Sicherheit Hinweise zur Sicherheit Symbol für Dokumentationsverweis. Wenn das Produkt mit diesem Symbol markiert ist, schlagen Sie bitte in der Produktdokumentation nach, um mehr Informationen über das Produkt zu erhalten. WARNING Eine WARNING in der Dokumentation symbolisiert eine Gefahr, die Verletzungen oder sogar Todesfälle verursachen kann.

  • Page 96: Considerazioni Sulla Sicurezza

    Safety and EMC Regulatory Statements Considerazioni sulla sicurezza Considerazioni sulla sicurezza Simbolo di riferimento alla documentazione. Se il prodotto è contras- segnato da questo simbolo, fare riferimento alla documentazione sul prodotto per ulteriori informazioni su di esso. WARNING La dicitura WARNINGdenota un pericolo che può causare lesioni o morte.

  • Page 97: Consideraciones Sobre Seguridad

    Safety and EMC Regulatory Statements Consideraciones sobre seguridad Consideraciones sobre seguridad Símbolo de referencia a la documentación. Si el producto va marcado con este símbolo, consultar la documentación del producto a fin de obtener mayor información sobre el producto. WARNING Una WARNING en la documentación señala un riesgo que podría resultar en lesiones o la muerte.

  • Page 98: Safety Information (japan)

    Safety and EMC Regulatory Statements Safety Information (Japan) Safety Information (Japan) J a p a n P o w e r C o r d W a r n i n g...

  • Page 99: Safety Information (china)

    Safety and EMC Regulatory Statements Safety Information (China) Safety Information (China)

  • Page 100: Emc Regulatory Statements, U.s.a, Canada, Australia/new Zealand, Japan

    Safety and EMC Regulatory Statements EMC Regulatory Statements EMC Regulatory Statements U.S.A. FCC Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against interference when the equipment is operated in a commercial environment.

  • Page 101: Korea, Taiwan

    Safety and EMC Regulatory Statements EMC Regulatory Statements Korea Taiwan...

  • Page 102: European Community

    2) This product was tested with HP branded products only. Roseville, 26-November-2008 Local contact for regulatory information: EMEA: Hewlett-Packard GmbH, HQ-TRE, Herrenberger Straße 140, D-71034 Böblingen, Germany U.S.: Hewlett-Packard, 3000 Hanover St., Palo Alto, CA 94304, U.S.A. 650-857-1501 D-10...

  • Page 103

    2) This product was tested with HP branded products only. Roseville, 01-December-2008 Local contact for regulatory information: EMEA: Hewlett-Packard GmbH, HQ-TRE, Herrenberger Straße 140, D-71034 Böblingen, Germany U.S.: Hewlett-Packard, 3000 Hanover St., Palo Alto, CA 94304, U.S.A. 650-857-1501 D-11...

  • Page 105: Waste Electrical And Electronic Equipment (weee) Statements

    Recycle Statements Waste Electrical and Electronic Equipment (WEEE) Statements Disposal of Waste Equipment by Users in Private Household in the European Union This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste.

  • Page 106

    Recycle Statements Waste Electrical and Electronic Equipment (WEEE) Statements Laitteiden hävittäminen kotitalouksissa Euroopan unionin alueella Jos tuotteessa tai sen pakkauksessa on tämä merkki, tuotetta ei saa hävittää kotitalousjätteiden mukana. Tällöin hävitettävä laite on toimitettava sähkölaitteiden ja elektronisten laitteiden kierrätyspisteeseen. Hävitettävien laitteiden erillinen käsittely ja kierrätys auttavat säästämään luonnonvaroja ja varmistamaan, että...

  • Page 107

    Recycle Statements Waste Electrical and Electronic Equipment (WEEE) Statements Smaltimento delle apparecchiature da parte di privati nel territorio dell'Unione Europea Questo simbolo presente sul prodotto o sulla sua confezione indica che il prodotto non può essere smaltito insieme ai rifiuti domestici. È responsabilità dell'utente smaltire le apparecchiature consegnan- dole presso un punto di raccolta designato al riciclo e allo smaltimento di apparecchiature elettriche ed elettroniche.

  • Page 108

    Recycle Statements Waste Electrical and Electronic Equipment (WEEE) Statements Descarte de Lixo Elétrico na Comunidade Européia Este símbolo encontrado no produto ou na embalagem indica que o produto não deve ser descartado no lixo doméstico comum. É responsabilidade do cliente descartar o material usado (lixo elétrico), encaminhando-o para um ponto de coleta para reciclagem.

  • Page 109

    Index Numerics 10/100Base-TX ports cabinet location on switch … 1-4 mounting the switch in … 2-11 1000Base-BX … C-3 cables fiber-optic cable specifications … C-3 connecting cables to switch ports … 2-27 1000Base-LH … C-3 effects of non-standard cables … 4-2 fiber-optic cable specifications …...

  • Page 110

    console checking messages during factory default configuration, restoring … 1-10, 4-11 troubleshooting … 4-9 Fan Status LED … 1-8, 2-20, 2-23 displaying the CLI prompt … 2-25 fan Status LED … 1-8 features … 2-24 Fault LED … 2-20, 2-23 how to connect in-band …...

  • Page 111

    behavior during self test … 2-7 Spd … 1-7 in-band … 3-1 Temp Status … 2-20, 2-23 in-band console access Usr … 1-7 types of … 2-24 LEDs, expansion module … 1-11 included parts … 2-1 LEDs, RPS/EPS … 2-19, 2-22 installation Link LEDs …...

  • Page 112

    passwords, deleting … 1-10 Reset button physical specifications, switch … A-1 description … 1-10 Ping test … 4-10 location on switch … 1-4, 1-10 pin-outs restoring factory default configuration … 4-11 twisted-pair cables … C-6 resetting the switch PoE LEDs … 1-7 factory default reset …...

  • Page 113

    switch transceivers SFP+ … 1-2 connecting to a power source … 2-18 troubleshooting … 4-1 description … 1-1 basic tips … 4-1 downloading new software … 4-12 checking port configuration … 4-3 electrical specifications … A-1 checking the console messages … 4-9 environmental specifications …...

  • Page 114

    6 – Index...

  • Page 116

    Technology for better business outcomes To learn more, visit www.hp.com/go/procurve/ © Copyright 2009-2010 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services.

This manual also for:

Procurve 2910al

Comments to this Manuals

Symbols: 0
Latest comments:
