Hearth and Home Technologies PVLP-SLP Installation Instructions Manual

Power vent low profile
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ā€¢ Important operating
1
Introduction

Table of Contents

1 Introduction
A. Components and Service Parts List . . . . . . . . . . . . . . . . . . 2
B. Installation of PVLP-SLP . . . . . . . . . . . . . . . . . . . . . . . . . . 3
A. Installation of Vent Pipe . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
B. Vent/Pipe Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
ā–ŗ
Requirements by Termination Type . . . . . . . . . . . . . . . . . 9
A. Framing and Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . 10
ā–ŗ
B. Termination Cap Clearances . . . . . . . . . . . . . . . . . . . . . . . 12
C. Installing Vent Cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
A. Wiring the Appliance for the PVLP-SLP with IntelliFireā„¢ Plus
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
(IFT) Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Control module (IFT-ECM) . . . . . . . . . . . . . . . . . . . . . . . . 27
1
Hearth & Home Technologies ā€¢ Power Vent Low Profile (PVLP-SLP) Instructions ā€¢ 4052-900 Rev. Mā€¢ 09/17
Power Vent Low Profile
DO NOT DISCARD THIS MANUAL
ā€¢ Read, understand and follow
a n d m a i n t e n a n c e
these instructions for safe
instructions included.
installation and operation.
PVLP-SLP
- Installation Instructions -
NOTICE
A. Installation Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
B. Setting the PVLP-SLP Baffle Adjustment . . . . . . . . . . . . . 28
C. Power Vent Operating Instructions . . . . . . . . . . . . . . . . . . 28
D. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
E. Replace Blower/Pressure Switch . . . . . . . . . . . . . . . . . . . 29
F. PVLP-SLP Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 31
Installation of the PVLP-SLP may be done by a quali-
fied service technician only. Installation MUST com-
ply with local, regional, state and national codes and
regulations.
IMPORTANT:
tions may create a possible hazard and will void the fire-
place warranty.
These instructions must remain with the equipment.
CAUTION! Risk of Cuts or Abrasions. Wear protective
gloves and safety glasses during installation. Sheet metal
edges are sharp.
INTRODUCTION
The Power Vent Low Profile (PVLP-SLP) is certified for
use as a horizontal termination cap only on fireplaces
manufactured by Hearth & Home Technologies with IPI (in-
termittent pilot ignition) gas controls. Fireplaces equipped
with millivolt type gas controls CANNOT use this product.
ā€¢ Leave this manual with
party responsible for use
and operation.
Failure to read and follow these instruc-
