Continuous external sine wave.
Input Impedance of External Clock Source: 50
Trigger Sources:
Software, Analog threshold comparator using internal D/
A to set trigger level, and External digital trigger
Trigger Modes:
Software-trigger, Pre-trigger, Post-trigger, Middle-trigger,
and Delay-trigger
AD Data Transfer Method: DMA (Bus mastering)

Digital Input

Number of channels:
Three TTL compatible inputs with 10K
resistor
Input Voltage:
Low: Min. 0V; Max. 0.8V
High: Min. +2.0V Max. 5.5V
Input Load:
Low:
0.5mA@ 5V
High: +2.7V min.@20mA max.

General Specifications

Connectors: 5 BNC-type, one 10-pin header
Operating Temperature: 0
Storage Temperature: -20
Humidity: 5 to 85%, non-condensing
Power Consumption: +5V @ 2.5A (maximum)
Dimension: 101mm(H) X 173mm(L)
Introduction
±
1uA @0V
Ω
° °
C to 40 C
° °
C to 80 C
Ω
pull down
