1

Introduction

PCI-9812/10 is an advanced performance data acquisition card
based on the 32-bit PCI Bus architecture. The maximum sampling
rate of PCI-9812/10 is up to 20M samples per second, with an
emphasis on continuous, non-stop, high-speed, and streaming of
A/D samples to host memory. The high performance design and
state-of-the-art technology makes this card ideal for DSP, FFT,
digital filtering, and image processing applications.

1.1 Features

PCI-9812 PCI Bus Advanced Data Acquisition Card is designed
with the following advanced features:
32-bit PCI-Bus, Bus Mastering DMA data transfer
12-bit (9812) or 10-bit (9810) analog input resolution
Onboard 32K words (samples) A/D FIFO memory
Up to 20MHz A/D sampling rate
Four single-ended analog input channels
Bipolar input signals
Four A/D converters simultaneously sampling
Five A/D trigger modes: software trigger, pre-trigger, Post-
trigger, middle trigger, and delay trigger

1.2 Applications

IF and BASEBAND Digitization
Ultrasound Imaging
Gamma Cameras
Test Instrument
CCD Imaging
Video Digitizing
Introduction 1
