ADLINK Technology NuDAQ PCI-9112 User Manual

Multi-function das card for pci / 3u compactpci
Hide thumbs Also See for NuDAQ PCI-9112:

Advertisement

Quick Links

Download this manual
Multi-function DAS Card for
This datasheet has been downloaded from
®
NuDAQ
PCI / 3U CompactPCI
User's Manual
Manual Revision: 4.0
Revision Date:
Part No:
PCI-9112
March 16, 2022
50M-00070-1000
http://www.digchip.com
at this
page

Advertisement

loading
Need help?

Need help?

Do you have a question about the NuDAQ PCI-9112 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADLINK Technology NuDAQ PCI-9112

Summary of Contents for ADLINK Technology NuDAQ PCI-9112

  • Page 1 ® NuDAQ PCI-9112 Multi-function DAS Card for PCI / 3U CompactPCI User’s Manual Manual Revision: 4.0 March 16, 2022 Revision Date: 50M-00070-1000 Part No: This datasheet has been downloaded from http://www.digchip.com at this page...
  • Page 2 Revision History Revision Release Date Description of Change(s) 3.90 Jan. 24, 2003 Updated release March 16, 2022 Product update release...
  • Page 3 PCI-9112 Preface Copyright © 2022 ADLINK Technology, Inc. This document contains proprietary information protected by copy- right. All rights are reserved. No part of this manual may be repro- duced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
  • Page 4 Conventions Take note of the following conventions used throughout this manual to make sure that users perform certain tasks and instructions properly. Additional information, aids, and tips that help users perform tasks. NOTE: NOTE: Information to prevent minor physical injury, component dam- age, data loss, and/or program corruption when trying to com- plete a task.
  • Page 5 PCI-9112 Table of Contents Revision History..............ii Preface ..................iii 1 Introduction ................ 1 Features................1 Applications ................. 2 Specifications............... 3 Software Support ..............5 2 Getting Started ..............9 Package Contents ............. 10 Device Layout and I/O Connectors........11 Jumper Settings..............
  • Page 6 This page intentionally left blank.
  • Page 7 PCI-9112 Introduction The PCI-9112 is a 12-bit, 110KHz, multifunction DAS data acquisi- tion card. The PCI-9112 DAS card uses state-of-the-art technol- ogy, making it ideal for data logging and signal analysis applications in medicine, process control, etc. 1.1 Features The PCI-9112 provides the following advanced features: 32-bit PCI bus 12-bit analog input resolution Onboard A/D FIFO memory...
  • Page 8 1.2 Applications Industrial and laboratory ON/OFF control Energy management Annunciation Security controller Product testing Event and frequency counting Waveform and pulse generation BCD interface driver Introduction...
  • Page 9 PCI-9112 1.3 Specifications Analog Input (A/D) ADS8922 or equivalent, Converter successive approximation type Resolution 12-bit Input Channels 16 Single-ended or 8 Differential Input Range Bipolar: ±10V, ± 5V, ±2.5V, ±1.25V, ±0.625V (Programmable) Unipolar: 0-10V, 0-5V, 0-2.5V, 0-1.25V Conversion Time 2 μ sec Throughput 110KHz multiplexing (maximum) Analog Input Over-voltage...
  • Page 10 Digital I/O (DIO) Channels 16 TTL compatible inputs and outputs Low: Min. 0V, Max. 0.8V Input Voltage High: Min. +2.0V Low: +0.5V at -0.2mA max. Input Load High: +2.7V at +20mA max. Low: Min. 0V; Max. 0.4V Output Voltage High: Min. +2.4V Low: Max.
  • Page 11 PCI-9112 1.4 Software Support ADLINK provides versatile software drivers and packages to suit various user approaches to building a system. Aside from pro- gramming libraries, such as DLLs, for most Windows-based sys- tems, ADLINK also provides drivers for other application environments such as LabVIEW.
  • Page 12 1.4.1 MAPS Core ADLINK MAPS Core is a software package that includes all the device drivers for Windows and a system level management tool called ACE (ADLINK Connection Explorer). With MAPS Core installed, the operating system can identify ADLINK devices and assign the necessary resources for low-level access, such as IO read/write or direct memory access.
  • Page 13 PCI-9112 ADLINK Connection Explorer (ACE) also provides a ready-to-use soft-front panel for digitizer products. Clicking the Launch button in the "Utility" block allows users to control digitizers through the UI and display the acquired waveform/data on the screen. 1.4.2 MAPS/LV, LabVIEW Support Customers who develop their own programs in LabVIEW must install the MAPS/LV software package.
  • Page 14 This page intentionally left blank. Introduction...
  • Page 15 PCI-9112 Getting Started This chapter describes the proper installation environment, installation procedures, package contents and basic information users should be aware of. Diagrams and images of equipment illustrated are for refer- ence only. Actual system configuration and specifications may vary. NOTE: NOTE: Getting Started...
  • Page 16 2.1 Package Contents Before continuing, check the package contents for any damage and check if the following items are included in the packaging: PCI-9112 Multifunction DAS Card PCI-9112 User’s Manual The card contains electro-static sensitive components that can easily be damaged by static electricity. Therefore, the card should be handled on a grounded anti-static mat.
  • Page 17 PCI-9112 2.2 Device Layout and I/O Connectors Figure 2-1: PCB Layout Getting Started...
  • Page 18 2.3 Jumper Settings The following items can be configured with jumpers: analog input signal mode counter’s clock source analog output range The card's jumpers and switches are preset at the factory. You can change the jumper settings for your own applications. Configuration Attributes Jumper...
  • Page 19 PCI-9112 2.3.2 Clock Source Settings A programmable interval timer is used in the PCI-9112. It provides 3 independent 16-bit programmable down counters. The input to counter 2 is connected to a precision 2MHz oscillator for the inter- nal pacer. The input of counter 1 is cascaded from the output of counter 2.
  • Page 20 2.3.3 D/A Reference Voltage Settings The D/A converter's reference voltage source can be supplied both internally and externally. The external reference voltage comes from connector CN3, Pin 31 (ExtRef1) and Pin12 (ExtRef2). The reference source of the D/A channel 1 and channel 2 are selected by JP4.
  • Page 21 PCI-9112 The internal D/A reference voltage can be set to –5V or –10V by JP3. The possible configurations are specified in the figure below. Note that the internal reference voltage is used only when the JP4 is set to internal reference only. -10V Reference Voltage is -5V (default setting)
  • Page 22 2.4 Connector Pin Assignments The PCI-9112 comes equipped with two 20-pin insulation dis- placement connectors (CN1 and CN2) and one 37-pin D-type con- nector (CN3). CN1 and CN2 are located on the board and CN3 is located on the faceplate. CN1 is for digital signal input, CN2 is for digital signal output, and CN3 is for analog input/output and timer/counter signals.
  • Page 23 PCI-9112 Signal Name Description Signal-ended Analog Input Channels 0-15 AI <0…15> Differential Analog High Input Channels 0-7 AIH <0…7> Differential Analog Low Input Channels 0-7 AIL <0…7> External Reference Voltage for D/A CH <1,2> ExtRef <1,2> Analog Output Channels <0,1> AO <0,1>...
  • Page 24 2.4.2 CN1/CN2: Digital Signal Input/Output CN1 and CN2 are 20-pin insulation displacement connectors for digital signal input/output with the following pin assignments. DI 0 DI 1 DI 2 DI 3 DI 4 DI 5 DI 6 DI 7 9 10 DI 8 DI 9 DI 10...
  • Page 25 PCI-9112 2.5 Hardware Installation Outline 2.5.1 PCI Configuration PCI cards (or CompactPCI cards) are equipped with plug and play PCI controllers and can request base addresses and interrupts according to PCI standards. The system BIOS will install the sys- tem resources based on the PCI cards’ configuration registers and system parameters (which are set by the system BIOS).
  • Page 26 2.5.3 Installation Procedures 1. Turn off your computer. 2. Turn off all peripherals connected to your computer (printer, monitor, etc.). 3. Remove the cover from your computer. 4. Setup jumpers on the PCI or CompactPCI card. 5. Select a 32-bit PCI slot. PCI slot are shorter than ISA or EISA slots, and are usually white or ivory.
  • Page 27 PCI-9112 2.6 Device Installation for Windows Systems Once Windows 7/10 has started, the Plug and Play function of Windows system will find the new NuDAQ cards. If this is the first time the NuDAQ cards are running on your Windows system, you will be prompted to input the device information source.
  • Page 28 2.7 Daughter Board Connection The PCI-9112 can be connected with five different daughter boards. The following are compatible: ACLD-8125, 9137, 9138, 9182, 9185, and 9188. The functionality and connections are specified in the following sections. 2.7.1 Connect with ACLD-8125 The ACLD-8125 has a 37-pin D-sub connector, which can connect to the PCI-9112 through the 37-pin assemble cable.
  • Page 29 PCI-9112 2.7.3 Connect with ACLD-9182 The ACLD-9182 is a 16-channel isolated digital input board. This board is connected to CN1 of the PCI-9112 via the 20-pin flat cable. The ACLD-9182 provides 500V DC isolation voltage protec- tion, thus protecting your PC system from damage in event that abnormal input signals occur.
  • Page 30 2.7.5 Connect with ACLD-9138/ACLD-9188 ACLD-9138 and ACLD-9188 are general-purpose terminal boards equipped with a 37-pin D-sub connector. The ACLD-9138 has an LED indicator to indicate the power ON/OFF status of your com- puter system. ACLD-9188 PCI-9112 Figure 2-6: ACLD-9138/9188 Daughter Board Connection Getting Started...
  • Page 31 PCI-9112 Operation Theory This chapter describes the operation theory of the PCI-9112 card functions. The functions include A/D conversion, D/A conversion, Digital I/O and counter/timer usage. The operation theory can help you to understand how to configure or to program the PCI-9112. 3.1 A/D Conversion Before programming the PCI-9112 to perform any A/D conver- sions, you should have an understanding of the following:...
  • Page 32 3.2 Analog Input Signal Connection The PCI-9112 provides 16 single-ended or 8 differential analog input channels. The analog signals can be converted to digital values by the A/D converter. To avoid ground loops and to obtain more accurate measurements, it is important to under- stand the signal source type and how to choose the analog input modes, either signal-ended or differential.
  • Page 33 PCI-9112 Differential Input Mode The differential input mode provides two inputs that respond to differences in signals. If the signal source has one side con- nected to local ground, the differential mode can be used to reduce the effect of ground loops. Figure 3-2 shows the con- nection for differential input mode.
  • Page 34 A differential mode must be used when the signal source is dif- ferential. A differential source means that the ends of the signal are not grounded. To avoid the danger of high voltages between the local ground of the signal and the ground of the PC system, a shorted ground path must be connected.
  • Page 35 PCI-9112 3.2.1 A/D Conversion Procedure A/D conversion starts when a trigger is set by the trigger source. The PCI-9112 provides three trigger modes. See section 3.2.2. While A/D conversion is in progress, the DRDY bit in the A/D status register is cleared and indicates that the data is not ready.
  • Page 36 Timer Pacer Trigger An FPGA is used as a trigger source for A/D conversion at a fixed rate. Two counters are cascaded together to generate trigger pulses with precise periods (see section 3.5). This mode is ideal for high speed A/D conversion. It can be combined with the DMA bus mastering or the interrupt data transfer.
  • Page 37 PCI-9112 DMA Transfer The DMA (Direct Memory Access) bus master allows data to be transferred directly between the PCI-9112 and the PC’s memory at the fastest possible rate, without using up any CPU time. The A/D data is queued in the local FIFO on the PCI-9112 itself and it is automatically transferred to PC's memory.
  • Page 38 3.3 D/A Conversion D/A conversion is less complex than A/D operation. You only need to write digital values into the D/A data registers and the corresponding voltage will be output to AO1 or AO2. The math- ematical relationship between the Digital number DAn and the output voltage is formulated as follows: Vout Vref...
  • Page 39 PCI-9112 3.4 Digital Input and Output The PCI-9112 provides 16 digital input and 16 digital output channels through the connectors CN1 and CN2 on-board. The digital I/O signal is fully TTL/DTL compatible. The digital I/O signals are illustrated in Figure 3-6. To program the digital I/O operation is fairly straightforward.
  • Page 40 3.5 Timer/Counter Operation The PCI-9112 has an interval timer/counter onboard. It offers 3 independent 16-bit programmable down counters; counter 1 and counter 2 are cascaded together for the A/D timer pacer trigger of A/D conversions, and counter 0 is free for user appli- cations.
  • Page 41 PCI-9112 Pacer Trigger Source Counters 1 and 2 are cascaded together to generate the timer pacer trigger for A/D conversion. The frequency of the pacer trigger is software controllable. The maximum pacer signal rate is 2MHz/4 = 500KHz which exceeds the maximum A/D conver- sion rate of the PCI-9112.
  • Page 42 This page intentionally left blank. Operation Theory...
  • Page 43 PCI-9112 Important Safety Instructions For user safety, please read and follow all instructions, Warnings, Cautions, and Notes marked in this manual and on the associated device before handling/operating the device, to avoid injury or damage. S'il vous plaît prêter attention stricte à tous les avertissements et mises en garde figurant sur l'appareil , pour éviter des blessures ou des dommages.
  • Page 44 Never attempt to repair the device, which should only be serviced by qualified technical personnel using suitable tools A Lithium-type battery may be provided for uninterrupted backup or emergency power. Risk of explosion if battery is replaced with one of an incorrect type;...
  • Page 45 PCI-9112 BURN HAZARD Touching this surface could result in bodily injury. To reduce risk, allow the surface to cool before touching. RISQUE DE BRÛLURES Ne touchez pas cette surface, cela pourrait entraîner des blessures. Pour éviter tout danger, laissez la surface refroidir avant de la toucher.
  • Page 46 This page intentionally left blank. Important Safety Instructions...
  • Page 47 San Jose, CA 95119-1208, USA Tel: +1-408-360-0200 Toll Free: +1-800-966-5200 (USA only) Fax: +1-408-600-1189 Email: info@adlinktech.com ADLINK Technology (China) Co., Ltd. 300 Fang Chun Rd., Zhangjiang Hi-Tech Park Pudong New Area, Shanghai, 201203 China Tel: +86-21-5132-8988 Fax: +86-21-5132-3588 Email: market@adlinktech.com ADLINK Technology GmbH Hans-Thoma-Straße 11...
