Optional) Securing The Access Point - Ruijie RG-AP530-I V2 Series Installation And Reference Manual

Before mounting the AP on the bracket, you must first install the Ethernet cables.
3) Slide the AP into the holes in the reverse direction against the arrow on the mounting bracket until it clicks into place.
Note: the "Ruijie" logo is facing up. See Figure 3-6.
Figure 3-6 Mounting the AP on the Bracket
When mounting the AP on the wall, keep the logo of Ruijie point upward.
The square feet should fit easily into the mounting slots. Do not forcibly push the AP into the slots.
After installation, verify that the AP is securely fastened.

3.5 (Optional) Securing the Access Point

1) Press the button and insert the lock hasp into the lock slot on the back of the bracket..
Figure 3-1 Pressing the button and insert the lock hasp
Press the button to release the lock hasp.
2) Align the lock loop protruding from the AP with the lock hasp hole.
Figure 3-8 Aligning the lock loop with the lock hasp hole
·
