Power Supply
Power Consumption
Environment
Installation
Protection Grade
Safety
EMC Compliance
Mechanical Vibration
Radio Approvals
MTBF
The above-mentioned weight refers to the total weight of the host and the bracket.
1.2 Product Image
The AP provides two radio ports, two Ethernet ports (one PoE-capable port and one console port) and one power port for
external power supply.
Figure 1-1 Appearance of RG-AP530-I V2
Remarks
①
Indicator
②
48V DC power port
③
Console port
④
1000BASE-T/100BASE-TX/10BASE-T Ethernet port (PoE-incapable)
Supports local power supply, DC 48V. (The power adapter is optional.)
supports the IEEE 802.3af standard
Maximum: 12.95W
Operating temperature: -10 º C to 50 º C
Storage temperature: -40 º C to 70 º C
Operating humidity: 5% to 95%(non-condensing)
Storage humidity: 5% to 95% (non-condensing)
Wall-mount
Ceiling-mount
IP41
GB4943, IEC 60950-1
GB9254, EN301 489, EN50155: EN50121
IEC61373
China Radio Transmission Equipment Type Approval Certificate
EN300 328
EN301 893
400,000H
·
