Ruijie RG-AP530-I V2 Series Installation And Reference Manual page 6

Fit AP
LED State
Off
Blinking green
Blinking red
Blinking blue
Blinking orange
Solid blue
Breathing blue
Solid red
Double blinking red
Fat AP
LED State
Off
Blinking green
Blinking red
Blinking orange
Solid blue
Breathing blue
Solid red
Double blinking red
Figure 1-2
Blinking Frequency
N/A
3 Hz
3 Hz
3 Hz
3 Hz
N/A
Alternating on and off, 16 cycles per
minute
N/A
3 Hz, blinking for 2 cycles and off for 2
cycles
Blinking Frequency
N/A
3 Hz
3 Hz
3 Hz
N/A
Alternating on and off, 16 cycles per
minute
N/A
3 Hz, blinking for 2 cycles and off for 2
cycles
Meaning
The AP is NOT receiving power/ in the
do-not-disturb status. This state can be disabled via
software.
Initialization in progress.
Initialization is complete, but no Ethernet activity on
either Ethernet port.
Initialization is complete, and the AP is establishing
a CAPWAP connection with an AC.
Firmware upgrade in progress. Do not power off.
The AP is operational and the CAPWAP connection
is established, but the wireless port is shut down.
The AP is operational, the CAPWAP connection is
established, and the wireless port is working.
AP alarm (The triggering condition needs defining.)
Locate a specific AP.
Meaning
The AP is NOT receiving power/ in the
do-not-disturb status. This state can be disabled via
software.
Initialization in progress.
Initialization is complete, but no Ethernet activity on
either Ethernet port.
Firmware upgrade in progress. Do not power off.
The AP is operational, but the wireless port is shut
down.
The AP is operational, , and the wireless port is
working.
AP alarm (The triggering condition needs defining.)
Locate a specific AP.
·
