Wiring Diagram - Directed DB3 Installation Manual

Wiring diagram

Refer to the Wiring Reference Chart for more information on specific wiring and connections.
With the exception of OBDII Diagnostic connector, all adapters are displayed from the wire side (unless specified otherwise).
(-) Ground
(+) Ignition Input
(+) 12V
Red or Red/Yellow,
7
Keyless Ignition Node
(Black conn. at PTS Switch)
6 5
Immo. Data:
White/Lt. Green,
pin 5
Cut
C2
(Lt. Gray conn. at BCM)
1 2
3 4
(+) 12V:
Parking Light (MUX):
White/Brown or
pin 3
White/Lt. Green,
HS CAN2 High: Gray, pin 3
HS CAN2 Low:
4 3 2 1
White, pin 11
(+) PTS: pin 4
Immo. Data (veh. side): Orange/Yellow: 9
(MUX) Parking Lights Output: Violet/Brown: 9
Immo. Data (veh. side): Yellow/Black: 10
pin 3
3
1 2 4 5 6
Black Connector
(at Headlight Switch)
HS CAN High: Gray/White, pin 6
OBDII
1 8
Diagnostic
Connector
9 16
HS CAN Low: Yellow, pin 14
HS CAN High: Tan/Black: 3
HS CAN Low: Tan: 4
HS CAN2 High: Orange/Green: 5
HS CAN2 Low: Orange/Brown: 6
Immo. Data (conn. side): Yellow: 8
Ignition Output: Yellow/Red: 11
(+) 12V: Brown/Red: 12
(+) PTS Output: Gray/Black: 7
403.CHRYSLER3 4.22 2013 Dodge/Ram Journey (Smart Key)
© 2016-11-23 Directed. All rights reserved.
(+) 12V
TX
(-) Ground
RX
