Connector - Directed DB3 Installation Manual

Input 10-pin black connector (H3)
Module
Conn./Pin Color
H3/1 Green
H3/2 Blue
H3/3 Red/White
H3/4 Red/Black
H3/5 Violet/Black
H3/6 White/Black
H3/7 Pink/White
H3/8 Violet
H3/9 Pink
H3/10 Blue/White
D2D 4-pin white connector (H4)
Module
Conn./Pin
H4/1
H4/2
H4/3
H4/4
RF 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
9
Description
W2W Only – (-) Lock Input
W2W Only – (-) Unlock Input
W2W Only – (-) Trunk Release/Tail Glass (if
applicable) Input
No Connection
[3]
No Connection
No Connection
W2W Only – (+) Parking Light Input
W2W Only – (+) Starter Input
No Connection
W2W Only – (-) Status (GWR) Input
Color
Green
Black
Blue
Red
Color
N/A
N/A
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
Description
(Data) TX
(-) Ground
(Data) RX
(+) 12 Volt
Description
RF Loop
RF Loop
(+/-) Wire Color
403.CHRYSLER3 4.22 2013 Dodge/Ram Journey (Smart Key)
© 2017-01-10 Directed. All rights reserved.
Ref.
