Installation - Directed DB3 Installation Manual

Vehicle connections
The connection information listed below is specific to the 2013 Dodge/Ram Journey (Smart Key). Refer to "Pre-installation and application warnings" for a list of important
notes.
Data 14-pin blue connector (H1)
Module
Conn./Pin Color
H1/1 Light Green
H1/2 Violet/Yellow
H1/3 Tan/Black
H1/4 Tan
H1/5 Orange/Green
H1/6 Orange/Brown
H1/7 Brown
H1/8 Yellow
H1/9 Orange or Orange/Yellow
H1/10 Orange/Red
H1/11 Yellow/Red
H1/12 Brown/Red
H1/13 Red
H1/14 Black
Output 12-pin red connector (H2)
Module
Conn./Pin Color
H2/1 Black/White
H2/2 Green/Black
H2/3 Green/White
H2/4 Red/Black
H2/5 Violet/White
H2/6 Gray
H2/7 Gray/Black
H2/8 Violet/Green
H2/9 Violet/Brown
H2/10 Yellow/Black
H2/11 Orange/Black
H2/12 Blue/Red
8
Description
No Connection
No Connection
HS CAN High
HS CAN Low
[2]
HS CAN High 2
[2]
HS CAN Low 2
No Connection
Relay 1 COM - (cut) Immo. Data (conn. side)
Relay 1 N.C. - (cut) Immo. Data (veh. side)
No Connection
Relay 2 COM - (+) Ignition Output
Relay 2 N.O. - (+) 12 V
W2W Only - (+) 12 Volt
W2W Only - (-) Ground
Description
W2W Only – (-) E-Brake Output
No Connection
W2W Only – (-) Door Status Output
W2W Only – (-) Trunk Status Output
[1]
W2W Only – (AC) Tach Output
W2W Only – (+) Brake Status Output
(+) PTS Output
No Connection
(MUX) Parking Lights Output
Immo. Data (veh. side)
No Connection
No Connection
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color
(+/-) Wire Color
403.CHRYSLER3 4.22 2013 Dodge/Ram Journey (Smart Key)
© 2017-01-10 Directed. All rights reserved.
