Module Programming - Directed DB3 Installation Manual

Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
Wait until the LED turns ON solid red, then remove the battery from the factory
1
keyless remote.
Use the tip of the remote to press twice on the Push-to-Start (PTS) button to turn the
2
ignition ON ("RUN" illuminates on the button). The LED flashes green.
3
Press on the PTS buttononce more to turn the ignition OFF.
Once again, use the tip of the remote to press twice on the Push-to-Start (PTS) button
4
to turn the ignition ON ("RUN" illuminates on the button). The LED flashes orange
slowly.
5
Click on Submit Key2GO Request.
Once the configuration is completed, reconnect the module. The LED turns ON solid
6
green for 3 seconds, then turns OFF.
Remove the module from the vehicle and reconnect it to your computer. The web site
7
will automatically recognize that you are moving onto the second phase of the
programming sequence.
Press the PTS button once more to turn the ignition OFF once the module is successfully
8
programmed.
You have successfully completed the module programming sequence.
11
403.CHRYSLER3 4.22 2013 Dodge/Ram Journey (Smart Key)
