  • Page 1 403.FORD4 v3.25 2017 Ford Escape...

  • Page 2: Table Of Contents

    Contents Introduction Vehicle function compatibilities Pre-installation and application warnings Wiring diagram Locating components in the vehicle Vehicle connections Module programming 2 Keys required! 1 Key required! Module programming for convenience only (skip transponder) Key2GO Connecting the module LED diagnostics and troubleshooting Soft reset Hard reset Feature programming...

  • Page 3: Introduction

    Introduction DB3 is an all-in-one door lock and override module. Warning! This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs Mobile application for smartphones. Refer to “Connecting the module” for more information. 403.FORD4 3.25 2017 Ford Escape...

  • Page 4: Vehicle Function Compatibilities

    Fuel level/EV battery level Brake Status (foot brake) Key2GO Door Locks Status Immobilizer Bypass-Data No Key Req'd E-Brake Status RAP Shut Down (Retained ACC Power) Ignition Status Remote Start Ready 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.

  • Page 5: Pre-Installation And Application Warnings

    [2] Tach: An optional connection required on some remote starters, which do not support a tach signal in D2D. [3] Unlock Dectection Output: Required to wake up the system from sleep mode in vehicles without one-touch window control. 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.

  • Page 6: Wiring Diagram

    (-) Unlock: White, pin 8 (+) 12V: Violet/Orange, pin 26 Red , Pin 1 Data TX: Data RX: Yellow/Orange, pin 54 Violet/Gray, pin 34 XKD2D65 (passenger side, behind glove box) 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.

  • Page 7: Locating Components In The Vehicle

    Locating components in the vehicle 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.

  • Page 8: Vehicle Connections

    BCM behind glove box, blue 60 pin plug (C), pin 54 data yellow/orange H2/11 Orange/Black (Data) RX BCM behind glove box, blue 60 pin plug (C), pin 34 data violet/gray 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.
  • Page 9 Conn./Pin Color Description H4/1 Blue (Data) TX H4/2 Black (-) Ground H4/3 Green (Data) RX H4/4 (+) 12 Volt RF 2-pin white connector (H5) Module Conn./Pin Color Description H5/1 H5/2 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.
  • Page 10 BCM, white 20 pin plug, pin 1 blue/white Tachometer [2] engine right side, black 8 pin plug, pin 1 (1.5L); front of engine, black green/blue (fuel injector 1) 16 pin plug, pin 1 (2.0L) 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.

  • Page 11: Module Programming

    Note: If the LED stays on solid red, check your connections and try again. Turn the key off when the module is successfully programmed. You have successfully completed the module programming sequence. 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.

  • Page 12: Key Required

    When the configuration is completed, reconnect the module. The LED will turn on solid green for 3 seconds, then turn off. Remove the key from the ignition barrel. You have successfully completed the module programming sequence. 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.

  • Page 13: Module Programming For Convenience Only (Skip Transponder)

    Turn ignition OFF and remove the key from the ignition barrel. 1st key out after 3-10 secs. The LED turns ON solid orange for 3 seconds then shuts OFF. Solid x3 Secs You have successfully completed the module programming sequence. 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.

  • Page 14: Key2Go

    Any first-time user must re-register to gain access to Key2GO, and some additional information will be required to complete the registration process, such as your Directed account number and store name. Key2GO is compatible with XKLoader2 and the online web tool, as well as XKLoader3 and the Directechs Mobile application.

  • Page 15: Connecting The Module

    4-pin D2D harness. (12-pin) (D2D) (10-pin) (14-pin) W2W installation If required: Connect the 10-pin and 12-pin harnesses to the module, then connect the 14-pin harness to the module. (12-pin) (10-pin) (14-pin) 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.

  • Page 16: Led Diagnostics And Troubleshooting

    External Module Synchronization Description Troubleshooting OBDII feature not supported. The diagnostic data bus was not detected, therefore the SmartStart features will be limited. (Flashes red, red, then orange) x 10 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.
  • Page 17 The smart key was not detected, which prevents the system from shutting down the vehicle. Flashes red x 3 Speed was detected. The vehicle was detected as moving, which prevents the system from shutting it down. Flashes red x 4 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.

  • Page 18: Soft Reset

    Wait 3 seconds until the LED turns ON solid orange, and wait 10 more seconds until the & LED starts to flash orange and red. Solid Flashes Release the programming button. The LED turns ON solid red. & Release Solid 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.

  • Page 19: Feature Programming

    To exit feature programming, press and hold the programming button for 3 seconds or ensure there is no activity on the interface for 30 seconds. The LED will turn ON orange for 2 seconds to confirm the end of the programming sequence. 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.

  • Page 20: Feature And Option List

    1. Disabled (no Factory No disarm operation on unlock or trunk. Transponder Ignition Alarm) Disarm with Unlock 2. Enabled* Will disarm vehicle by cycling the ignition before unlocking or opening trunk. 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.

  • Page 21: Limited One Year Consumer Warranty

    This Warranty gives you specific legal rights and you may also have other rights which vary from state to state. VOXX DEI LLC, 2351 J. Lawson Blvd., Orlando, Florida 32824 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.

  • Page 22: Quick Reference Guide

    Press & hold for 1 second to remote start. * Press & hold for 5 seconds to activate the trunk release (optional). * Icon and remote appearance may differ depending on the model purchased. 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.
  • Page 23 Notes 403.FORD4 3.25 2017 Ford Escape ©2023 Directed. All rights reserved.
