Obdii - Directed DB3 Installation Manual

Wiring diagram with T-Harness (THCHD3)
These T-Harness connectors are NOT interchangeable. They fot ONLY the appropriate vehicles.
With the exception of OBDII Diagnostic connector, all adapters are displayed from the wire side (unless specified otherwise).
OR
(+) Ignition Input
(+) 12V
(-) Ground
Black Connector
(at Headlight Switch)
(+) 12V:
Red or Red/Yellow,
pin 3
6
6-pin
Connectors
T-01
male
Female
OR
Connect T-Harness
male connector
into PTS switch male
Keyless Ignition Node
(Black conn. at PTS switch)
Parking Light (MUX):
White/Brown or
White/Lt. Green,
pin 3
3
1 2 4 5 6
Black Connector
(at Headlight Switch)
The Remote Start Safety
Override Switch is inactive
(used for RSR only)
T-02
male
Female
Connect T-Harness
male connector
into PTS switch
(+) Ignition Output: Yellow/Red
(MUX) Parking Lights Output: Violet/Brown
Not Connected: Orange/Black

OBDII

Diagnostic Connector
THCHD3 Rev. 1
(optional T-Harness)
(+) 12V
TX
(-) Ground
RX
403.CHRYSLER3 4.22 2013 Dodge/Ram Journey (Smart Key)
© 2016-11-23 Directed. All rights reserved.
D2D
only
Do not
connect
