Directed DS4+ Installation Manual page 9

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information
Function Color
Pontiac Vibe 2009-2010
RX Lt. Blue
TX Tan
Starter 1 Black
Starter 2 (2.4L only) White
Ignition 1 Brown
Ignition 2 Green
HS CAN High Lt. Green
HS CAN Low White
Parking Lights Brown
12V White
Scion xB 2008-2010
RX Pink
TX Green
12V White
Starter 1 White
Starter 2 White
Ignition 1 Gray
Ignition 2 White
HS CAN High Lt. Green
HS CAN Low White
Parking Lights White
9
Pin Polarity Location
4 Data Transponder Key Amplifier on ignition switch.
5 Data Transponder Key Amplifier on ignition switch.
8 (+) Ignition switch.
1 (+) Ignition switch.
6 (+) Ignition switch.
4 (+) Ignition switch.
6 Data OBDII.
14 Data OBDII.
18 (-) Headlight switch.
1 (+) Dash fuse box.
4 Data Transponder Key Amplifier on ignition switch.
5 Data Transponder Key Amplifier on ignition switch.
7 (+) Ignition switch.
8 (+) Ignition switch.
1 (+) Ignition switch.
6 (+) Ignition switch.
4 (+) Ignition switch.
6 Data OBDII.
14 Data OBDII.
18 (-) Headlight switch.
Connector Information
Color
Black
Black
White
White
White
White
White
White
White
White
Black
Black
White
White
White
White
White
Black
Black
White
© 2017-11-27 Directed. All rights reserved.
Pins Ref.
7 A
7 A
8 B
8 B
8 B
8 B
16 C
16 C
20 D
1 E
7 A
7 A
8 B
8 B
8 B
8 B
8 B
16 C
16 C
20 D
DS4+ TL11
